Sony VPL-FH30
WUXGA Projector, 4300 Lumens

OUR PART #  VPLFH30

Call for Details


Sony's VPL-FH30 is designed to fit smoothly into almost any environment where a high-quality projector is required. Its brightness, zoom and throw range, coupled with its wide lens shift range, mean it can perform where other projectors would struggle - even in high ambient light.

Once installed, the VPL-FH30 has excellent image capabilites and a long lifespan that delivers low Total Cost of Ownership. Sony's BrightEra technology improves and maintains color purity throughout the life of the system by protecting the LCD panels against harmful ultra violet light. Clever features such as synchronized lamp and filter replacement cycles reduce costs and downtime.

Featuring the usual wide range of inputs, an external monitor connection for the presenter's convenience, and advanced projection capabilities such as side-by-side image projection and DICOM medical training, the VPL-FH30 is an ideal projector choice for venues that demand quality and practicality.

This product comes with PrimeSupport - fast, hassle-free repairs and a helpline offering expert technical advice.

FEATURES

  • 3LCD XGA BrightEra Panel Technology - Sony's BrightEraPanel Technology gives more accurate color rendition, higher brightness andlonger lifespan for a lower Total Cost of Ownership.
  • Ultra High Resolution - The VPL-FH30's WUXGA (1920x1200)16:10 format resolution delivers high image quality.
  • Very High Brightness: 4,300 Lumens Color Light Output -With very high brightness of 4,300 Lumens Color Light Output, the VPL-FH30give a clearer image in high ambient light, making it highly suitable forlarger venues.
  • Wide Zoom Range (x1.6) and Throw Ratio (1.4 to 2.3) asStandard - The standard lens has a wide zoom capability and throwratio, offering more flexibility over the positioning of the projector, whichcan be installed closer to or further away from the screen.
  • Wide Lens Shift Range: Vertical +60%, Horizontal +/-32% -The VPL-FH30's wide lens shift range means that the projector can bepositioned closer to the ceiling, or horizontally offset to avoid ceilingobstacles.
  • Long Lamp Replacement Time: 3,000-4,000 hours (high/std)- Longer lamp life means fewer visits by maintenance personnel and lower TotalCost of Ownership.
  • Lamp/Filter Replacement Cycles Synchronized -Synchronized lamp and filter replacement effectively halves the number ofvisits needed to maintain the projector in peak operating condition (filtersare provided with replacement lamps.)
  • Interchangeable Lenses: Z1024, Z1032 - The VPL-FH30allows you to choose different lenses for increased flexibility.
  • Side by Side Image Projection - Side by side twin imageprojection gives you the ability to project from two inputs (RGB + any otherInput) at the same time, making the projector ideal for applications likevideo conferencing and DICOM medical training.
  • DICOM GSDF Simulation - The VPL-FH30 offers DICOM GSDFSimulation (HDMI with computer signals), which conforms to GSDF (GrayscaleStandard Display FUnction) of medical standards for DICOM (Digital Imaging andCommunication in Medicine).
  • Wide Range of Image Adjustments - This wide range ofimage adjustments allows the projector to be installed in almost any location.Where is equipment is being upgraded, installers are more likely to be able touse existing mounts. In new installations, they are more likely to be able towork around existing obstructions.
  • User Panel Alignment - Pixel alignment shifts theentire image or desired range (H:16 x V:10 pixels) for complete colorcorrection.
  • Color Matching - The VPL-FH30 offers brightness and colormatching adjustment to the original image for complete image accuracy.
  • Lower Operating Power Consumption than Previous Models -Lower operating power consumption helps reduce energy consumption and lowersrunning costs.

SPECIFICATIONS

Display System

  • 3 LCD system

Display Element

  • Effective Display Size: 0.76" (19.3mm) X3, BrightEra, Aspect Ratio 16:10
  • Effective Pixels: 6,912,000 (1920 X 1200 X 3) Pixels

Projection Lens

  • Zoom: Manual (Approx 1.6x)
  • Focus: Manual
  • Lens Shift: Manual, Vertical: Upward 60% to Downward 0% Horizontal: Right32% to Left 32%
  • Light Source: High Pressure Mercury Lamp - 275W
  • Recommended Lamp Replacement: Approx. 3000H (Lamp Mode: High) Approx.4000H (Lamp Mode: Standard)
  • Filter Cleaning Cycle: Max15000H / At the time of lamp replacement
  • Screen Size: 40 to 600 (1.02 to 15.24m)
  • Luminous Flux (Brightness): 5000lm (Lamp Mode: High) // 4000lm (Lamp Mode:Standard)
  • Color Luminous Flux (Color Brightness): 5000lm (Lamp Mode: High) // 4000lm(Lamp Mode Standard)
  • Contrast Ratio: Max. 2000:1
  • Speaker: None

Displayable Scanning Frequency

  • Horizontal: 14kHz to 93kHz
  • Vertical: 47Hz to 93Hz

Display Resolution

  • Computer Signal Input: Maximum Display Resolution: 1920 X 1200 Dots(Resizing Display) Panel Display Resolution: 1920 X 1200 Dots
  • Video Signal Input: NTSC, PAL, SECAM, 480/60i, 567/50i, 480/60p, 576/50p,720/60p, 720/50p, 1080/60i, 1080/60p, 1080/50p
  • Color System: NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
  • V.Keystone Correction: Max. +/- 5 Degrees
  • OSD Language: 20 languages (English, Dutch, Italian, German, Spanish,Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, SimplifiedChinese Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Persian)

Computer and Video signal input/output

  • Other Signal Input/Output: RS-232C Connector: D-Sub 15 pin (Female) LANConnector: RJ45, 10BASE-T/100BASE-TX Control S Input Connector: Stereo MiniJack, Plug in power DC5V
  • Operating Temperature (Operating Humidity):  0 to 40° C/32 to104° F (35 to 85% (No Condensation))
  • Storage Temperature (Storage Humidity): -20 to 60° C/-4 to 140° F(10 to90%)
  • Power Requirements: AC 100 to 240V. 50/60Hz
  • Input A: RGB / Y PB PR Connector: 5BNC (Female) Audio Input Connector:Stereo Mini Jack
  • Input B: RGB Input Connector: Mini D-Sub 15pin (Female) // Audio inputconnector: Stereo Mini Jack (shared with INPUT C)
  • Input C: DVI-D Input Connector: DVI-D 24 pin (Single Link), supported HDCP// Audio input connector: Stereo mini jack (Shared with INPUT B)
  • Input D: HDMI Input Connector: Digital RGB/Y PB PR
  • S Video In: S Video Input Connector: Mini DIN 4 pin Audio Input Connector:Pin Jack x 2 (Shared with Video In)
  • Video In: Video Input Connector: Pin Jack // Audio input connector: PinJack (x2) (Shared with S Video In)
  • Output: Monitor Output Connector: Mini D-Sub 15 pin (Female) Audio OutputConnector: Stereo Mini Jack (variable out)

Power Consumption

  • AC100V: Max. 400W
  • AC240V: Max 380W

Standby Mode Power Consumption

  • AC100V: Max. 400W
  • AC240V: Max. 380V

Standby Mode Power Consumption

  • AC100V: 9W (Standby Mode: Standard) / 0.15W (Standby Mode: Low)
  • AC240V: 10W (Standby Mode: Standard) / 0.3W (Standby Mode: Low)

Heat Dissipation

  • AC100V: 1365 BTU
  • AC240V: 1297 BTU
  • Safety Regulations: WW Model
  • Body Color: White / Gray
  • Standard Outside Diemsions: Approx. W 390 X H 148 X D 477mm (W15-11/32" x H 5-13/16" x D 18-25/32")
  • Weight: Approx. 8.0Kg / 17.7lbs

Supplied Accessories

  • RM-PJ19 Remote Commander (1) (Battery : Size AA (R6) / Approx. 18g / x 2)
  • Size AA (R6) Batteries (2)
  • AC Power Cord(1)
  • Cable Clamp (2)
  • Quick Reference Manual
  • Warranty Card (1) (outside of box)
  • Security Label (1)
  • Operating Instructions CD-ROM





Sony VPL-FH30
WUXGA Projector, 4300 Lumens

OUR PART #  VPLFH30

Product Information:

Sony's VPL-FH30 is designed to fit smoothly into almost any environment where a high-quality projector is required. Its brightness, zoom and throw range, coupled with its wide lens shift range, mean it can perform where other projectors would struggle - even in high ambient light.

Once installed, the VPL-FH30 has excellent image capabilites and a long lifespan that delivers low Total Cost of Ownership. Sony's BrightEra technology improves and maintains color purity throughout the life of the system by protecting the LCD panels against harmful ultra violet light. Clever features such as synchronized lamp and filter replacement cycles reduce costs and downtime.

Featuring the usual wide range of inputs, an external monitor connection for the presenter's convenience, and advanced projection capabilities such as side-by-side image projection and DICOM medical training, the VPL-FH30 is an ideal projector choice for venues that demand quality and practicality.

This product comes with PrimeSupport - fast, hassle-free repairs and a helpline offering expert technical advice.

FEATURES

  • 3LCD XGA BrightEra Panel Technology - Sony's BrightEraPanel Technology gives more accurate color rendition, higher brightness andlonger lifespan for a lower Total Cost of Ownership.
  • Ultra High Resolution - The VPL-FH30's WUXGA (1920x1200)16:10 format resolution delivers high image quality.
  • Very High Brightness: 4,300 Lumens Color Light Output -With very high brightness of 4,300 Lumens Color Light Output, the VPL-FH30give a clearer image in high ambient light, making it highly suitable forlarger venues.
  • Wide Zoom Range (x1.6) and Throw Ratio (1.4 to 2.3) asStandard - The standard lens has a wide zoom capability and throwratio, offering more flexibility over the positioning of the projector, whichcan be installed closer to or further away from the screen.
  • Wide Lens Shift Range: Vertical +60%, Horizontal +/-32% -The VPL-FH30's wide lens shift range means that the projector can bepositioned closer to the ceiling, or horizontally offset to avoid ceilingobstacles.
  • Long Lamp Replacement Time: 3,000-4,000 hours (high/std)- Longer lamp life means fewer visits by maintenance personnel and lower TotalCost of Ownership.
  • Lamp/Filter Replacement Cycles Synchronized -Synchronized lamp and filter replacement effectively halves the number ofvisits needed to maintain the projector in peak operating condition (filtersare provided with replacement lamps.)
  • Interchangeable Lenses: Z1024, Z1032 - The VPL-FH30allows you to choose different lenses for increased flexibility.
  • Side by Side Image Projection - Side by side twin imageprojection gives you the ability to project from two inputs (RGB + any otherInput) at the same time, making the projector ideal for applications likevideo conferencing and DICOM medical training.
  • DICOM GSDF Simulation - The VPL-FH30 offers DICOM GSDFSimulation (HDMI with computer signals), which conforms to GSDF (GrayscaleStandard Display FUnction) of medical standards for DICOM (Digital Imaging andCommunication in Medicine).
  • Wide Range of Image Adjustments - This wide range ofimage adjustments allows the projector to be installed in almost any location.Where is equipment is being upgraded, installers are more likely to be able touse existing mounts. In new installations, they are more likely to be able towork around existing obstructions.
  • User Panel Alignment - Pixel alignment shifts theentire image or desired range (H:16 x V:10 pixels) for complete colorcorrection.
  • Color Matching - The VPL-FH30 offers brightness and colormatching adjustment to the original image for complete image accuracy.
  • Lower Operating Power Consumption than Previous Models -Lower operating power consumption helps reduce energy consumption and lowersrunning costs.

SPECIFICATIONS

Display System

  • 3 LCD system

Display Element

  • Effective Display Size: 0.76" (19.3mm) X3, BrightEra, Aspect Ratio 16:10
  • Effective Pixels: 6,912,000 (1920 X 1200 X 3) Pixels

Projection Lens

  • Zoom: Manual (Approx 1.6x)
  • Focus: Manual
  • Lens Shift: Manual, Vertical: Upward 60% to Downward 0% Horizontal: Right32% to Left 32%
  • Light Source: High Pressure Mercury Lamp - 275W
  • Recommended Lamp Replacement: Approx. 3000H (Lamp Mode: High) Approx.4000H (Lamp Mode: Standard)
  • Filter Cleaning Cycle: Max15000H / At the time of lamp replacement
  • Screen Size: 40 to 600 (1.02 to 15.24m)
  • Luminous Flux (Brightness): 5000lm (Lamp Mode: High) // 4000lm (Lamp Mode:Standard)
  • Color Luminous Flux (Color Brightness): 5000lm (Lamp Mode: High) // 4000lm(Lamp Mode Standard)
  • Contrast Ratio: Max. 2000:1
  • Speaker: None

Displayable Scanning Frequency

  • Horizontal: 14kHz to 93kHz
  • Vertical: 47Hz to 93Hz

Display Resolution

  • Computer Signal Input: Maximum Display Resolution: 1920 X 1200 Dots(Resizing Display) Panel Display Resolution: 1920 X 1200 Dots
  • Video Signal Input: NTSC, PAL, SECAM, 480/60i, 567/50i, 480/60p, 576/50p,720/60p, 720/50p, 1080/60i, 1080/60p, 1080/50p
  • Color System: NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N, PAL60
  • V.Keystone Correction: Max. +/- 5 Degrees
  • OSD Language: 20 languages (English, Dutch, Italian, German, Spanish,Portuguese, Turkish, Polish, Russian, Swedish, Norwegian, Japanese, SimplifiedChinese Traditional Chinese, Korean, Thai, Vietnamese, Arabic, Persian)

Computer and Video signal input/output

  • Other Signal Input/Output: RS-232C Connector: D-Sub 15 pin (Female) LANConnector: RJ45, 10BASE-T/100BASE-TX Control S Input Connector: Stereo MiniJack, Plug in power DC5V
  • Operating Temperature (Operating Humidity):  0 to 40° C/32 to104° F (35 to 85% (No Condensation))
  • Storage Temperature (Storage Humidity): -20 to 60° C/-4 to 140° F(10 to90%)
  • Power Requirements: AC 100 to 240V. 50/60Hz
  • Input A: RGB / Y PB PR Connector: 5BNC (Female) Audio Input Connector:Stereo Mini Jack
  • Input B: RGB Input Connector: Mini D-Sub 15pin (Female) // Audio inputconnector: Stereo Mini Jack (shared with INPUT C)
  • Input C: DVI-D Input Connector: DVI-D 24 pin (Single Link), supported HDCP// Audio input connector: Stereo mini jack (Shared with INPUT B)
  • Input D: HDMI Input Connector: Digital RGB/Y PB PR
  • S Video In: S Video Input Connector: Mini DIN 4 pin Audio Input Connector:Pin Jack x 2 (Shared with Video In)
  • Video In: Video Input Connector: Pin Jack // Audio input connector: PinJack (x2) (Shared with S Video In)
  • Output: Monitor Output Connector: Mini D-Sub 15 pin (Female) Audio OutputConnector: Stereo Mini Jack (variable out)

Power Consumption

  • AC100V: Max. 400W
  • AC240V: Max 380W

Standby Mode Power Consumption

  • AC100V: Max. 400W
  • AC240V: Max. 380V

Standby Mode Power Consumption

  • AC100V: 9W (Standby Mode: Standard) / 0.15W (Standby Mode: Low)
  • AC240V: 10W (Standby Mode: Standard) / 0.3W (Standby Mode: Low)

Heat Dissipation

  • AC100V: 1365 BTU
  • AC240V: 1297 BTU
  • Safety Regulations: WW Model
  • Body Color: White / Gray
  • Standard Outside Diemsions: Approx. W 390 X H 148 X D 477mm (W15-11/32" x H 5-13/16" x D 18-25/32")
  • Weight: Approx. 8.0Kg / 17.7lbs

Supplied Accessories

  • RM-PJ19 Remote Commander (1) (Battery : Size AA (R6) / Approx. 18g / x 2)
  • Size AA (R6) Batteries (2)
  • AC Power Cord(1)
  • Cable Clamp (2)
  • Quick Reference Manual
  • Warranty Card (1) (outside of box)
  • Security Label (1)
  • Operating Instructions CD-ROM
