OUR PART #: BETA-10CX MFR #: BETA-10CX
Recommended for professional audio vocal wedges, or mid-bass in a sealed enclosure. Also works well in a vented enclosure as a satellite or monitor. ...Read more
Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.
Email customer service
Recommended for professional audio vocal wedges, or mid-bass in a sealed enclosure. Also works well in a vented enclosure as a satellite or monitor.
Specification
Nominal Basket Diameter 10", 254mm
Nominal Impedance* 8 ohms
Power Rating**
Watts 250W
Music Program 500W
Resonance 49.32Hz
Usable Frequency Range 60Hz - 4kHz
Sensitivity*** 94.3dB
Magnet Weight 38 oz.
Gap Height 0.31", 7.92mm
Voice Coil Diameter 2", 50.8mm
Mounting Information
Recommended Enclosure Volume
Sealed 14.16-42.48 liters / 0.5-1.5 cu.ft.
Vented 15.29-87.78 liters / 0.54-3.1 cu.ft.
Driver Volume Displaced 71.3 cu.in. / 1.17 liters
Overall Diameter 10.08", 256.03mm
Baffle Hole Diameter 9.18", 233.17mm
Front Sealing Gasket Fitted as standard
Rear Sealing Gasket Fitted as standard
Mounting Holes Diameter 0.25", 6.35mm
Mounting Holes B.C.D. 9.66", 245.36mm
Depth 3.98", 101.09mm
Net Weight 7.3 lbs, 3.31 kg
.
