Yamaha HD Venue 2-Channel Rackmount Wireless System, without Microphones

OUR PART #: 01-HDVENU-NM MFR #: 01HDVENUNM

Copied to clipboard

The HD Venue Dual-Channel rack-mounted wireless microphone system is the perfect audio solution for video conferencing or voice reinforcement applications. ...Read more

Yamaha HD Venue 2-Channel Rackmount Wireless System, Without Microphones Image 1
Yamaha HD Venue 2-Channel Rackmount Wireless System, Without Microphones
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The HD Venue Dual-Channel rack-mounted wireless microphone system is the perfect audio solution for video conferencing or voice reinforcement applications. Its rack-mounted design allows you to integrate the Venue easily into video conferencing products, or audio equipment.

The Venue Dual Channel wireless system consists of a rack-mountable base station, and an HD wireless dual-microphone charger base. The Venue supports up to two HD audio wireless microphones. With frequency groups, the Venue allows for installation of two Venue systems with a maximum of four microphones in the same area.

Includes

  • Rackmount receiver
  • Dual mic charging station
  • Wireless microphones

Features

  • Superior Audio Quality - Wideband frequency response provides high definition audio delivering spoken word clarity
  • Wireless Freedom - Lets users sit anywhere within a conference room or walk around freely
  • Support for Multiple Microphones - Wearable, tabletop boundary and handheld as well as Countryman Adapter for earset microphone
  • No More Cell Phone Buzz - RF Armor technology lets microphones operate even when in direct contact with other wireless electronic devices
  • Secure - 128-bit encryption prevents unwanted users from listening

Specifications

  • AUDIO
    • Channels: 2 channels per system
    • Radio Frequency
      • North and South America: 1920 to 1930 MHz
      • Africa, Asia, Australia and Europe: 1880 to 1900 MHz (DECT EU)
      • Mainland China: 1900 to 1920 MHz
      • Japan: 1893.5 to 1906.1 MHz
    • Range: 300 feet (90 meters) approx. (no obstruction) with out-of-range alarm
    • Bandwidth: 50-14,000 Hz
  • BASE STATION
    • Power: 5V DC, 1A locking power connector 100-240V, 50-60 Hz; Power Supply included
    • Connectors/Interfaces
      • Channel LED indicators
      • Pairing Push Buttons
      • USB port for firmware update only
      • Configuration DIP Switches (8)
      • Channel 1 Analog Output 1/4 inch or male XLR jacks
      • Channel 2 Analog Output 1/4 inch or male XLR jacks
      • Channel 1 Analog Input 1/4 inch/XLR combo jacks
      • Channel 2 Analog Input 1/4 inch/XLR combo jacks
    • CHARGER BASE
      • Power: 5V DC, 1A 100-240V, 50-60 Hz; Power Supply included
      • Connectors: 2 proprietary 4 pin microphone charge jacks

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

Product Documents

Click to download
