Electro-Voice EVF1151S-WHITE
Single 15" Front Loaded Bass Element Loudspeaker - White

OUR PART #:  EVF1151S-WHITE

The Electro-Voice® EVF-1151S is a high power...
Learn More
Our Price: $1,639.00

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Electro-Voice EVF1151S-WHITE
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The Electro-Voice® EVF-1151S is a high power, front-loaded bass element that can be used in a variety of applications where high quality sound reinforcement is required in a lightweight package.

The EVF-1151S utilizes the EVS15SB 15” woofer uses FEA optimization for motor, suspension, and electrical design for very low distortion and maximum intelligibility at high SPL levels.

The EVF-1151S features make it a professional loudspeaker for any fixed install application. The trapezoidal enclosure is constructed out of weather resistant birch, and coated with EVCoatTM for maximum protection from the elements. The unique acoustic and rigging design allows for vertical and horizontal clusters to be built using any combination of loudspeakers from the entire EVF & EVH Series, with an assortment of Full-Range, Low Frequency and Subwoofer loudspeakers, it gives you the tools to maximize flexibility of system design, no matter what the application and budget. The innovative input panel provides choice of phoenix style connector (included in all standard models) or the ability to add; a dual NL4 type connector cover plate or gland nut cover plate (for weatherizing applications). An available 70.7/100 Volt transformer kit simply mounts to the input panel for use in distributed systems. All these features give you the flexibility to do a large range of venues with fewer items in inventory and quickly support your customer’s requirements.

Features:

  • Color: White (Not pictured)
  • EVS15SB 15” (381mm) LF Transducer
  • 103 dB Sensitivity, 135 dB Maximum SPL
  • System Rating: 400W Continuous, (1600W Peak)
  • (22) M10 Threaded Suspension Points

Specifications:

  • Freq. Response (-3 dB): 67 Hz - 95 Hz
  • Freq. Range (-10 dB): 46 Hz - 124 Hz
  • Rec. Hipass Frequency: 35 Hz
  • Axial Sensitivity1: 103 dB (1W/1m)
  • Max. Calculated SPL1: 135 dB
  • Horizontal Coverage: Omnidirectional
  • Vertical Coverage: Omnidirectional
  • Power Handling: 400W Continuous, 1600W Peak
  • LF Transducer: EVS15SB, 15 in (381mm) Driver
  • Nominal Impedance: 4 Ohms (Passive), 8 Ohms (Biamp)
  • Connectors: (2) 4 Contact 10 AWG Phoenix/ EuroBlock Style Screw Terminal;
    -PI Version: Gland Nut with Included Input Panel Cover
  • Enclosure Material: 13 Ply Weather Resistant Birch
  • Grille: 16 GA Galvanneal, Powder coat, with Rotatable Logo;
    -PI Version:Stainless Steel with Hydrophobic Cloth
  • Suspension: (22) M10 Threaded Points
  • Dimensions (H x W x D): 30.26” x 18.50” x 18.37”
  • Net Weight: 62.6 lb
