MIPRO MTM90 6B Wireless UHF Interlinking Transmitter, 6B Frequency Set (for MA708PA, MA808PA PA Systems Series)

The MIPRO MTM-90 is a UHF receiver module designed for use with MIPRO's MA708PA and MA808PA series systems. This model is preset to the 6B frequency band.

MIPRO MTM-90 (6B) Features:

• 6B Frequency Band Preset
• High/Low power output selectable
• Modularized design allows easy installation, operation and trouble-free maintenance
• Fits MA-708 & MA-808 wireless portable PA systems (installed in top double slot)
• Allows wireless transmission to multiple active power speakers to expand coverage and extend range
• Ideal for parade routes, farmers markets, outdoor athletic event or religious services or any where you need to add more systems wirelessly, without the mess of bulky speaker cables

MIPRO MTM-90 (6B) Specifications:

• Frequency range: 644-668MHz
• Oscillation Mode: PLL Synthesized
• Bandwidth: 24 MHz
• RF Output Power: 10 mW / 100 mW (switchable)
• Spurious Emissions: < -45 dBm
• Physical:
  • Dimensions: 8.6" W x 2.2" H x 7.5" D (220 x 57 x 190mm)
  • Weight: Approx. 14.5 oz (410 g)
