JBL AC2215/00 15" 2-Way Speaker with 100x100 Coverage, White

The JBL AC2215/00 is a compact 2-way full-range loudspeaker system comprised of one 380 mm (15") low frequency driver and one 38 mm (1.5") exit / 44 mm (1.75") voice-coil compression driver. The PT™ Progressive Transition™ waveguide provides wide 100° by 100° coverage. High-slope passive crossovers minimize band overlap.

Applications

• Small performing arts facilities
• Theatrical sound design
• Auditoriums
• Sports facilities
• Themed entertainment venues
• Delay / fill locations of larger systems

Features

• 100° x 100° coverage
• PT Progressive Transition waveguide for good pattern control with low distortion
• Bi-amp / passive switchable
• Optional U-bracket for easy installation

Specifications

• Frequency Range: 42 Hz - 19 kHz (-10 dB)
• Frequency Response: 50 Hz - 17 kHz (±3 dB)
• Crossover Modes: Bi-amp / passive switchable
• Transducer Power Rating (AES):
  • LF: 275W (1100W peak), 2 hrs; 250W (1000W peak), 100 hrs
  • HF: 50W (200W peak), 2 hrs
• Long-Term System Power Rating (IEC): Passive mode: 250W (1000W peak), 100 hrs
• Maximum SPL:
  • Bi-amp mode:
    • LF: 121 dB-SPL cont avg (127 dB peak)
    • HF: 129 dB-SPL cont avg (135 dB peak)
  • Passive mode: 121 dB-SPL cont avg (127 dB peak)
• System Sensitivity: Passive Mode: 97 dB SPL
• Nominal Impedance: 8 Ω
