TOA BA-235
Power Amp, 35W, 4 Ohms Line Input

OUR PART #  BA235CU

Our Price: $210.56
List Price: $260.56
You save 19%! (Low Price Guarantee)
In Stock

Recommended Accessories

The TOA BA-235 is a 35 W power amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms. When used in conjunction with the optional mixer amplifier BG-220 (20 W) or BG-235 (35 W), 2-channel broadcast can be made.

TOA BA-235 Specifications:

  • Power Source: 120 V AC
  • Rated Output: 35 W
  • Power Consumption: 90 W (rated output)
  • Frequency Response: 50 Hz - 20 kHz
  • Total Harmonic Distortion: 0.5 % or less
  • Input: Line In: 0 dB*/+4 dB (selectable) removable terminal block or RCA jack
  • Output: Speaker: 4 Ohm balanced, Bridge: parallel in Line in
  • Output Regulation: 2 dB or less
  • S/N Ratio: 80 dB or more (Band Pass: 20 Hz - 20 kHz)
  • Tone Control: Bass: ±10 dB at 100 Hz
  • Control: Master gain control, Input Level selector switch
  • Indicator: Power LED
  • Other Feature: Automatic electronic drive limiter
  • Operating temperature: 0° to +35°C (32°F to 95° F)
  • Operating Humidity: 35 % to 80 %RH (no condensation)
  • Finish: Panel: ABS resin, Case: Steel plate
  • Dimensions: 210 (W) × 94.3 (H) × 265 (D) mm (8.27 × 3.71" ×10.43)
  • Weight: 4 kg (8.82 lb)
  • Accessory:
    Volume control cover: YA-920 ……1
    Removable teminal plug(2 pins) ……3
    Removable teminal plug (4 pins) ……1
    Option  Rackmounting bracket: MB-25B-BK
Rack kit for BG Series, black, single mountTOA MB-25B-BK Rack kit for BG Series, black, single mount

Rack kit for TOA BG series.  Will work with A-903/906/912MK2, M-900MK2, P-906/912MK2 and A-706/712/724 series as well.(Amp not included)

In Stock

Our Price:$25.99List Price: $32.17You save 19%!

Rack kit for BG series, dual mountTOA MB25B-J Rack kit for BG series, dual mount

The TOA MB-25B-J is designed to mount two BG-115s (BG-130s) in a single rack. When using this bracket,remove four plastic feet provided on the bottom surface of each amplifier and joint the two amplifiers with a  metal connector, as ...

Usually ships in 7-14 business days.
Need it sooner? Call us!

Our Price:$25.99List Price: $32.17You save 19%!

Volume CoverTOA YA920 Volume Cover

Volume Control Cover for 900MK2 Series, Black.

Usually ships in 7-14 business days.
Need it sooner? Call us!

Our Price:$2.83List Price: $3.50You save 19%!

Click to download

TOA BA-235
Power Amp, 35W, 4 Ohms Line Input

OUR PART #  BA235CU

Product Information:

The TOA BA-235 is a 35 W power amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms. When used in conjunction with the optional mixer amplifier BG-220 (20 W) or BG-235 (35 W), 2-channel broadcast can be made.

TOA BA-235 Specifications:

  • Power Source: 120 V AC
  • Rated Output: 35 W
  • Power Consumption: 90 W (rated output)
  • Frequency Response: 50 Hz - 20 kHz
  • Total Harmonic Distortion: 0.5 % or less
  • Input: Line In: 0 dB*/+4 dB (selectable) removable terminal block or RCA jack
  • Output: Speaker: 4 Ohm balanced, Bridge: parallel in Line in
  • Output Regulation: 2 dB or less
  • S/N Ratio: 80 dB or more (Band Pass: 20 Hz - 20 kHz)
  • Tone Control: Bass: ±10 dB at 100 Hz
  • Control: Master gain control, Input Level selector switch
  • Indicator: Power LED
  • Other Feature: Automatic electronic drive limiter
  • Operating temperature: 0° to +35°C (32°F to 95° F)
  • Operating Humidity: 35 % to 80 %RH (no condensation)
  • Finish: Panel: ABS resin, Case: Steel plate
  • Dimensions: 210 (W) × 94.3 (H) × 265 (D) mm (8.27 × 3.71" ×10.43)
  • Weight: 4 kg (8.82 lb)
  • Accessory:
    Volume control cover: YA-920 ……1
    Removable teminal plug(2 pins) ……3
    Removable teminal plug (4 pins) ……1
    Option  Rackmounting bracket: MB-25B-BK
Rack kit for BG Series, black, single mountTOA MB-25B-BK Rack kit for BG Series, black, single mount

Rack kit for TOA BG series.  Will work with A-903/906/912MK2, M-900MK2, P-906/912MK2 and A-706/712/724 series as well.(Amp not included)

In Stock

Our Price:$25.99List Price: $32.17You save 19%!

Rack kit for BG series, dual mountTOA MB25B-J Rack kit for BG series, dual mount

The TOA MB-25B-J is designed to mount two BG-115s (BG-130s) in a single rack. When using this bracket,remove four plastic feet provided on the bottom surface of each amplifier and joint the two amplifiers with a  metal connector, as ...

Usually ships in 7-14 business days.
Need it sooner? Call us!

Our Price:$25.99List Price: $32.17You save 19%!

Volume CoverTOA YA920 Volume Cover

Volume Control Cover for 900MK2 Series, Black.

Usually ships in 7-14 business days.
Need it sooner? Call us!

Our Price:$2.83List Price: $3.50You save 19%!

Click to download
