TOA BG-235 CU 3-Channel Mixer and Power Amplifier, 35W

OUR PART #: BG235CU MFR #: BG-235 CU

Copied to clipboard

The BG-235 is a 35W three-input mixer amplifier for background music and general announcement. ...Read more

TOA BG-235 CU 3-Channel Mixer And Power Amplifier, 35W Image 1
TOA BG-235 CU 3-Channel Mixer And Power Amplifier, 35W
Our Price: $272.50
List Price: $337.30
You save 19%!
Synchrony Music & Sound Card
No Interest if paid in full within 6 Months
Learn How

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The BG-235 is a 35W three-input mixer amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms, and is equipped with the MOH OUT that permits 2-channel broadcast when used in conjunction with the optional booster amplifier BA-235 (35W) or BA-260 (60W).

THE TOA BG-200 Series Mixer / Amplifiers are ideal solutions for installations in restaurants, retail stores, lounges, classrooms and meeting rooms. Incorporating TOA's no-compromise technology, the new BG-200 Series are designed to provide the high performance and audio quality with wide frequency response, low noise and distortion and stable output regulation. With an impressive 35W of power, the BG-235 offers a simple and cost-effective solution for adding powered zones to an existing system, as well as powering speakers in applications that require a line input from a mix or playback source. Using the perfected amplifier technology and bullet-proof construction that has made TOA an industry standard, the BG-200 Series Mixer / Amplifier is designed to make sound projects affordable, reliable and easy to install. The BG-200 Series Amplifiers are UL / cUL approved, competitively priced and backed by TOA's 5-year warranty.

Includes

  • Volume control cover: YA-920
  • Removable teminal plug (2 pins)
  • Removable teminal plug (4 pins)

Features

  • 3-channel, 35W mixer / amplifier
  • All inputs/outputs with removable Euro-block connections for easy installation
  • 3 inputs: mic / line with balanced Phoenix input, Lines 2 and 3 with Phoenix & RCA Summing
  • MOH / Zone2 balanced line output assignable via rear-panel DIP switches
  • Mute receivable assignable for channels 2 & 3 on rear-panel DIP switches

Specifications

  • Power Source: 120VAC
  • Rated Output: 35W
  • Power Consumption: 90W (rated output)
  • Frequency Response: 50Hz - 20kHz
  • Total Harmonic Distortion: 0.5% or less
  • Input: Mic: -60dB* / Line 1: -10dB, Mic / Line 1 selectable, Line 2
  • Output: Speaker: 4Ω balanced, MΩ: 0dB, Line: 0dB
  • Output Regulation: 2dB or less
  • S / N Ratio: Mic/Line 1: 60dB or more (Band Pass: 20Hz- 20kHz)
  • Tone Control: Bass: ±10dB @ 100Hz
  • Control: Mic/Line 1 gain control, Bass tone control, Mute control (Manual mute), Mic / Line 1 selector switch, MOH assign switch (Mic / Line 1)
  • Indicator: Power LED
  • Other Feature: Automatic electronic drive limiter
  • Operating temperature: 32°F to 95°F (0°C to +35°C)
  • Operating Humidity: 35% to 80% RH (no condensation)
  • Finish: Panel: ABS resin, Case: Steel plate
  • Dimensions (WxHxD): 8.27" x 3.71" x 10.43"(210 x 94.3 x 265mm)
  • Weight: 8.82lbs (4kg)
