Leviton N3004-00D 3000 Series 4-Channel DMX Controller

OUR PART #: N3004-00D MFR #: N3004-00D

Copied to clipboard

The Leviton N3004-00D DMX lighting console offers 4 channels of control, scene memory, and several chase options, providing easy lighting effects at the touch of a button. ...Read more

Leviton N3004-00D 3000 Series 4-Channel DMX Controller Image 1
Leviton N3004-00D 3000 Series 4-Channel DMX Controller Image 2
Leviton N3004-00D 3000 Series 4-Channel DMX Controller Image 3
Leviton N3004-00D 3000 Series 4-Channel DMX Controller
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

The Leviton N3004-00D DMX lighting console offers 4 channels of control, scene memory, and several chase options, providing easy lighting effects at the touch of a button. Many of the most often used features are documented on the bottom of the console. Connector pin outs are permanently screened next to the connector.

Leviton N3004-00D DMX Controller Features:

  • DMX512 output
  • 4 dimming control channels
  • 4 recordable scene memory
  • Chaser functions:
    • 2 selectable chases
    • Channel chase
    • Scene chase
    • Speed control
    • Direction control
    • Audio input
  • Bump buttons for each channel or scene
  • Master output fader

Leviton N3004-00D DMX Controller Specifications:

  • Power Supply: +100 – 240VAC "wall wart"
  • Control Signal: DMX512-A
  • Connector: 3-pin or 5-pin female XLR
  • Audio Input: Maximum input: -10 db 100mV
  • Dimensions (WxHxD): 9.13" x 6.7" x 2.2" (232 x 170 x 56 mm)
  • Weight: 2.4 lbs (1.2 kg)
  • Shipping Weight: 3.0 lbs (1.5 kg)
