Product Overview
Simple, fast setup in less than 30 seconds. Should feedback occur, a filter activates that kills ONLY the feedback, not the rest of the audio.
Features
- Performs like a very advanced set of automatic parametric filters
- Increased headroom and reduced noise floor
- Provides more gain before feedback (6 to 9dB typical)
- Transparent - leaves your sound clear and untouched
- Time required to find and eliminate feedback: 0.4 seconds, typical @ 1kHz
Specifications
- Filters:
- 12 independent digital notch filters per channel, controlled automatically from 40 Hz to 20 KHz.
- Filter width: user-controllable - either 1/10 or 1/5 octave, constant "Q"
- Resolution: 1 Hz
- Time required to find and eliminate feedback: 0.4 seconds, typical @ 1kHz
- Number of Dynamic vs. Fixed filters per channel: user selectable. Last configuration stored in memory.
- Input and Output:
- Input/Output Maximum Signal Levels: Balanced +18dBV peak, unbalanced +12 dBV peak
- Output Drive: Unit will perform as specified driving a load >600 Ohms
- Input Impedance: Balanced or unbalanced >40K Ohms, PIN 2 high
- Output Impedance: Balanced or unbalanced 150 Ohms nominal, PIN 2 high
- Bypass: True power off bypass
- Headroom: +14 dB peak @ 4 dBV nominal input, balanced
- I/O Connectors: XLR-3 and 1/4" TRS
- Performance:
- Frequency response: 20 Hz – 20kHz +/- 0.3 dB
- Gain matching: +/- 0.2 dB
- Spectral Variation: + .25 dB, 20Hz to 20 kHz
- SNR - Dynamic Range: >108 dB
- THD:
- .005% at 1 kHz
- < 0.01% 20 Hz – 10 kHz
- < 0.025% 10 KHz – 20 kHz
- Dynamic Range: >105 dB
- Power Input:
- 115 VAC: 100 – 130 VAC 50/60 Hz
- 230 VAC: 200 – 240 VAC 50/60 Hz
- 115 VAC, 0.1 A, 10 W, 0.160 A SB fuse
- 230 VAC, 0.06A, 10 W, 0.080 A T fuse
- Dimensions: 1-U rack mount; 19" x 1.75" x 6.25"
- Weight: 8.0 lbs. (3.6 kg) nominal
- Safe operating temperature: -15 to +50° C ambient temperature (5 to 122° F)
