Blackmagic Design Studio Videohub
1RU 16x32 3G-SDI Video Router with 16 Deck Control Ports

OUR PART #:  STUDIO-VIDEOHUB

Blackmagic Design's Studio Videohub is perfect for smaller workgroups who need compact size at an affordable cost.
Learn More
Our Price: $2,827.28
List Price: $2,995.00
You save 6%!

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

Blackmagic Design Studio Videohub
Qty:
In Stock

Similar Products

Blackmagic Design's Studio Videohub is perfect for smaller workgroups who need compact size at an affordable cost. Studio Videohub has the exact same high performance features of the larger models, including 3 Gb/s SDI, auto standard detection for SD, HD and 3 Gb/s HD-SDI formats, re-clocking and more. Studio Videohub features 16 inputs, 32 outputs and 16 deck control ports all packed into a tiny 2 rack unit size less than an inch thick. Studio Videohub uses the same power supply as the larger models and the same powerful software.

No manual patching
In the past most studios have been forced to use manual patching to connect editing workstations and decks. However this can become too complicated for creative designers, graphic artists and editors to understand, plus it gets even more complicated as your studio grows. Manual patching also caused problems with limited SDI cable lengths, and patch cables quickly wear out, so you get glitches as other uses bump them while patching.

Videohub eliminates this problem because everyone is permanently connected, and no cables need to be physically changed ever. All video connections are changed from an easy to use software application right from your computer desktop. Unlike manual patching, Videohub re-clocks the SDI video signal for long cable lengths. Plus unlike manual patching, you can send one SDI video connection to as many outputs as you like, so mulitple people can access any SDI video source, all at the same time.

High end post production and broadcasters have understood the advantages of professional routing switchers for decades, and now with Videohub, everyone can afford these same workflow advantages.

Industrial Strength Routing Switcher
Blackmagic Design's Videohub routers are not only based on a revolutionary design but they also have the most advanced electronics technology available today. All Videohub routers include SDI re-clocking so even the longest distance equipment from your router can be connected together. Combined with redundant power supplies, power fail protection and high reliaibility single PCB construction, Videohub routers are true broadcast quality.

SDI Re-Clocking
Videohub also includes built in SDI re-clockers on each SDI input which regenerate the SDI video signal. Every inch of video cable from your SDI video devices degrades the SDI signal. Expensive premium grade "digital" cables can help, however simply cannot eliminate this loss. With SDI re-clocking you can have a regenerated and clean SDI signal out to all the SDI devices in your studio. That means longer cable lengths, and no glitches in your video.

Simultaneous SD, HD or 3 Gb/s Video
Videohub makes it easy to run Standard Definition and High Definition equipment now and add 3 Gb/s SDI equpiment in the future. That's because Videohub handles mixed SD, HD and 3 Gb/s SDI connections all on the same router at the same time. Videohub automatically detects when an SDI input changes, and instantly sets all SDI outputs connected to that input to match. SDI re-clocking and output SDI slew rates change automatically.

Independent Monitoring
Because most editors love monitoring direct from the router, Videohub has up to 144 independent SDI outputs totally dedicated for monitoring. Independent monitoring outputs are great when you need to quickly look at decks and other editing systems in your facility. You can also use the extra outputs to connect consumer VHS and DVD recorders via external converters.

Deck Control Routing
With up to 144 independent Sony compatible RS-422 serial control ports included, each editing system can control any deck in your facility. Each deck control connection is independently reversible via software control, so it's easy to connect edit stations or decks to any of the deck control ports.

World's Highest Quality 3 Gb/s SDI
With the exciting new 3 Gb/s SDI connections built-in, Videohub allows twice the SDI data rate than normal HD-SDI. Use 3 Gb/s SDI for high resolution real time 2048 x 1556 feature film editing. 3 Gb/s SDI has full compatibility with SD, HD or 2K in 4:4:4 or 4:2:2 all with a single BNC cable. With 3 Gb/s SDI built-in, you have full compatibility with all your current standard definition SDI and high definition SDI eqiupment, plus any new formats that come along in the future. With Videohub, your studio is future proof.

Network Router Control
Videohub uses software control panels that run on Windows and Mac OS X. This lets you control the router from the same system you edit on. Videohub connects to any computer via USB and is then shared over your local network. Any computer can be the host, and simply connecting to the router via the USB 2.0 connection activates that computer as the host and allows other computers on your network to connect. Router labels can be changed from any computer and are fully unicode compatible for foreign language support.

Blackmagic Design Studio Videohub Specifications:

  • SDI Video Input: 16x 10 bit SD-SDI, HD-SDI, 3Gb/s HD and 2Kswitchable
  • SDI Video Outputs: 32x 10 bit SD-SDI, HD-SDI, 3Gb/s HD and 2K switchable
  • Multi Rate Support: Auto detection of SD, HD or 3Gb/s SDI. Simultaneous routing of 2K, HD and SD video
  • Device Control: 16x bidirectional Sony-compatible RS-422 deck control ports. Serial ports TxRx pin reversible under software control
  • Router Control: USB 2.0 high speed interface shared over IP network
  • Updates and Configuration: USB 2.0 high speed(480Mb/s) interface
  • Re-clocking: On all SDI inputs, auto switching between standard definition, high definition or 3 Gb/s SDI video
  • SD Format Support: 625/25 PAL and 525/29.97 NTSC
  • HD Format Support: 1080p24, 1080p25, 1080p30,1080i48, 1080i50, 1080i59.94, 720p30, 720p50, 720p59.94 and 720p60
  • 2K Format Support: 2048 x 1556/23.98 and 24
  • SDI Compliance: SMPTE 292M, SMPTE 259M, SMPTE 296M, SMPTE 425M-A, SMPTE 425M-B, ITU-R BT.656 and ITU-R BT.601
  • SDI Video Sampling: 4:2:2 and 4:4:4 when using 2 routes
  • SDI Video Rates: SDI video connections are switchable between standard definition, high definition and 2K. SDI switches between 270Mb/s standard definition SDI, 1.5 Gb/s HD-SDI and 3 Gb/s HD and 2K SDI
  • SDI Color Precision: 4:2:2 and 4:4:4 10 bit when using 2 routes
  • SDI Color Space: YUV, or RGB when using 2 routes
  • SDI Metadata Support: Video payload identification ancillary data as per SMPTE 352M
  • SDI Audio Sampling: Television standard sample rate of 48kHz and 24 bit
  • SDI Auto Switching: Automatically selects between SD-SDI, HD-SDI and 3 Gb/s SDI on each input so that each input can be running a different television standard
  • Software Control: Router control included free for Windows and Mac OS X
  • Firmware Upgrade: Via included firmware updater application
  • Installation: 2 rack unit size. Less than 1" deep
  • Power Supply: 1x Universal power supplies included. IEC power cables required
  • Power Fail Protection: Router connections preserved and restored instantly at power on independently of host computer
  • Product Warranty: 3 year limited manufacturer's warranty
