QSC AD-S28TW
Sub Surface Mount Black

OUR PART #  AD-S28TW

Our Price: $690.00
(Low Price Guarantee)
Usually ships in 7-14 business days.
Need it sooner? Call us!

The AcousticDesign Series of installation loudspeaker products from QSC expands with the new AD-S28Tw surface mount subwoofer system. Designed to supplement audio systems by adding low-frequency extension, the new AD-S28Tw is acoustically matched to the entire AD Series. Rated for 250 watts continuous power handling and able to take up to 700 watt peaks, the AD-S28Tw is a great complement to any of the ceiling-mount or surface-mount AD Series models.

The dual 8" woofers are equipped with polypropylene cones for protection in humid environments. The bandpass enclosure features two chambers. One chamber is completely sealed, while the other chamber features a large port. The bandpass design allows for tight precise bass with extension down to 36 Hz. This highly efficient design produces a 1W at 1m sensitivity of 94 dB SPL. The AD-S28Tw has a built-in passive low-pass filter set at 120 Hz.

The marine grade plywood enclosure is built to the highest standard to provide exceptional resistance to high humidity. The zinc-plated steel grille has a black foam backing, molded ABS endcaps and a rotatable logo. On the rear of the enclosure is the input cup with a hinged door to conceal the controls and input connections. Input and output nickel plated screw terminals accept wiring from 18 AWG (1.02 mm) to 12 AWG (2.053 mm). Two rotary switches can be found in the input cup. One switch selects between the 70V / 100V transformer taps, while the other switch enables or disables the internal passive low-pass filter.

The AD-S28Tw can be deployed in a number of ways. With the included rubber feet attached, the subwoofer can be floor or shelf-standing. Suspended installation is available with either the included forged-shoulder eyebolts and accessories or the included steel yoke.

Features:

  • Dual 8" polypropylene cone woofers
  • Large port area for extended low-frequency performance
  • Dual chamber ported bandpass cabinet
  • Defeatable passive 120 Hz low-pass filter with impedance compensation
  • 250 watts continuous power handling, 700 watts peak
  • 70/100 V multitap transformer with 8 ohm bypass
  • Yoke mount and flying hardware included
  • Marine grade plywood construction

Specifications:

  • Configuration  Surface mount bandpass subwoofer, ported
  • Low-frequency Transducer  Dual 8" (200 mm) weather resistant, polypropylene cone woofers, rubber surround
  • Frequency Range
      Frequency Response (-6 dB)  42 Hz – 165 Hz
      Useable Frequency Range (-10 dB)  36 Hz – 205 Hz
  • Filter  120 Hz low-pass, passive, bypassable
  • Maximum Output
      Calculated Peak / Continuous Output
      2pi (half space)  124 dB SPL / 118 dB SPL
      4pi (full space)  118 dB SPL / 112 dB SPL
  • Nominal Impedance  8 ohms
  • Power Rating
    RMS Power Handling   250 W (2 hours IEC)
    Recommended Max Amp Power  500 W RMS
  • Sensitivity  94 dB, 2.83 V, 1 m, half space (2pi)
  • Transformers
    Type  Custom low distortion laminated core, wide bandwidth design
    Taps  70V: 200, 100, 50, 25 W / 100V: 200, 100, 15 W / 8 ohms selected by switch
  • Enclosure
  • Material  Marine grade plywood, ABS, steel grille
  • Environmental  Exceeds Mil Spec 810 for humidity, salt spray and dust; IEC 60529 IP-X4 splash rating
  • Finish  Textured black paint
  • Grille  Painted steel
  • Connectors  4 position barrier strip; 2 in / 2 out
  • Mounting Hardware
    Black powder coated steel yoke with attachment hardware
    Black zinc coated forged shoulder steel M6 eyebolts
    Black powder coated steel shear plates with attachment hardware
    Black rubber feet with integral threaded bolt
  • Weight  43 lb (19.5 kg) / 55 lb (25 kg)



QSC AD-S28TW
Sub Surface Mount Black

OUR PART #  AD-S28TW

Product Information:

The AcousticDesign Series of installation loudspeaker products from QSC expands with the new AD-S28Tw surface mount subwoofer system. Designed to supplement audio systems by adding low-frequency extension, the new AD-S28Tw is acoustically matched to the entire AD Series. Rated for 250 watts continuous power handling and able to take up to 700 watt peaks, the AD-S28Tw is a great complement to any of the ceiling-mount or surface-mount AD Series models.

The dual 8" woofers are equipped with polypropylene cones for protection in humid environments. The bandpass enclosure features two chambers. One chamber is completely sealed, while the other chamber features a large port. The bandpass design allows for tight precise bass with extension down to 36 Hz. This highly efficient design produces a 1W at 1m sensitivity of 94 dB SPL. The AD-S28Tw has a built-in passive low-pass filter set at 120 Hz.

The marine grade plywood enclosure is built to the highest standard to provide exceptional resistance to high humidity. The zinc-plated steel grille has a black foam backing, molded ABS endcaps and a rotatable logo. On the rear of the enclosure is the input cup with a hinged door to conceal the controls and input connections. Input and output nickel plated screw terminals accept wiring from 18 AWG (1.02 mm) to 12 AWG (2.053 mm). Two rotary switches can be found in the input cup. One switch selects between the 70V / 100V transformer taps, while the other switch enables or disables the internal passive low-pass filter.

The AD-S28Tw can be deployed in a number of ways. With the included rubber feet attached, the subwoofer can be floor or shelf-standing. Suspended installation is available with either the included forged-shoulder eyebolts and accessories or the included steel yoke.

Features:

  • Dual 8" polypropylene cone woofers
  • Large port area for extended low-frequency performance
  • Dual chamber ported bandpass cabinet
  • Defeatable passive 120 Hz low-pass filter with impedance compensation
  • 250 watts continuous power handling, 700 watts peak
  • 70/100 V multitap transformer with 8 ohm bypass
  • Yoke mount and flying hardware included
  • Marine grade plywood construction

Specifications:

  • Configuration  Surface mount bandpass subwoofer, ported
  • Low-frequency Transducer  Dual 8" (200 mm) weather resistant, polypropylene cone woofers, rubber surround
  • Frequency Range
      Frequency Response (-6 dB)  42 Hz – 165 Hz
      Useable Frequency Range (-10 dB)  36 Hz – 205 Hz
  • Filter  120 Hz low-pass, passive, bypassable
  • Maximum Output
      Calculated Peak / Continuous Output
      2pi (half space)  124 dB SPL / 118 dB SPL
      4pi (full space)  118 dB SPL / 112 dB SPL
  • Nominal Impedance  8 ohms
  • Power Rating
    RMS Power Handling   250 W (2 hours IEC)
    Recommended Max Amp Power  500 W RMS
  • Sensitivity  94 dB, 2.83 V, 1 m, half space (2pi)
  • Transformers
    Type  Custom low distortion laminated core, wide bandwidth design
    Taps  70V: 200, 100, 50, 25 W / 100V: 200, 100, 15 W / 8 ohms selected by switch
  • Enclosure
  • Material  Marine grade plywood, ABS, steel grille
  • Environmental  Exceeds Mil Spec 810 for humidity, salt spray and dust; IEC 60529 IP-X4 splash rating
  • Finish  Textured black paint
  • Grille  Painted steel
  • Connectors  4 position barrier strip; 2 in / 2 out
  • Mounting Hardware
    Black powder coated steel yoke with attachment hardware
    Black zinc coated forged shoulder steel M6 eyebolts
    Black powder coated steel shear plates with attachment hardware
    Black rubber feet with integral threaded bolt
  • Weight  43 lb (19.5 kg) / 55 lb (25 kg)
