Ensemble Designs BE-72
BrightEye SDI to HDMI Converter, Color Corrector, and Broadcast Confidence Monitor

OUR PART #:  BE-72

Combine Ensemble Design's BrightEye 72 SDI to HDMI converter with any HDMI monitor for high-end display applications in broadcast and post.
Learn More
Our Price: $617.50
List Price: $650.00
You save 5%!
Be the first to review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

Ensemble Designs BE-72
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Combine Ensemble Design's BrightEye 72 SDI to HDMI converter with any HDMI monitor for high-end display applications in broadcast and post. Color correction and temperature adjustments are made easy with the front panel and computer controls. Open captions, timecode and audio presence can be displayed on your monitor giving you confidence your signal is correct.

Front panel controls include: complete proc amp, built-in test signals for use in aligning the monitor, graticule, H/V pulse delay, on screen audio VU meters, timecode burn in, AFD indicator and open caption decoding.

BrightEye 72 can display open captions on any HDMI video monitor. 608 or 708 caption data is decoded and displayed on-screen.

Audio presence is reported and on-screen VU meters show all 16 audio channels. If audio or Dolby E are embedded on the SDI input, audio is passed through on the HDMI output.

Ensemble Design BE-72 Features:

  • Turn Any Monitor into a High-End Broadcast Monitor
  • Built-in Color Corrector – Great for Adjusting Color Temperature of On-Set Monitors
  • Broadcast Confidence Monitor Features Including Caption Decoding, Timecode Display, AFD and Audio Level Meters
  • H & V Shift for Easy Trouble Shooting
  • Safe Title/Graticule Overlay
  • Mirror Output Mode for On-Camera Talent
  • Use in Post with 4:4:4 Material
  • Analog Audio Outputs
  • Use with HD or SD Monitors, VTRs and Projectors
  • Optical input available on BrightEye 72-F

Ensemble Design BE-72 Specifications:

  • Dimensions (WxHxD): 5.63” x 0.8” x 5.98” (143 x 21 x 152 mm) including connectors and flange
  • Weight: 14 oz
  • Power: 12 volts, 7 watts (100-230 VAC modular power supply)
  • Temperature Range: 0° to 40° C ambient (all specs met)
  • Relative Humidity: 0 to 95%, non-condensing
  • Serial Digital Input:
    • Impedance 75 O: Return Loss >15 dB to 2.97 GHz
    • Max Cable Length:
      • 300 meters for 270 Mb/s
      • 100 meters for 1.485 Gb/s
      • 70 meters for 2.97 Gb/s
  • Optical Input:
    • Wavelength: 830 to 1610 nm
    • Receiver Sensitivity: -18 dBm
    • Max Cable Length: 20 km
    • Fiber Type: Single Mode, Multi-mode compatible with attenuation at transmit end
  • SDI Standards Supported:
    • 1080i (SMPTE 274M -4,5,6) 50, 59.94 or 60 Hz
    • 720p (SMPTE 296M -1,2,3) 50, 59.94 or 60 Hz
    • 1080p (SMPTE 274M -9,10,11) 23.98, 24, 25 Hz
    • 1080sF (RP211 -14,15,16) 23.98, 24, 25 Hz
    • 1080p (SMPTE 424M, 425M), 50, 59.94, 60, Level A
    • 525i, 625i (SMPTE 259M)
  • HDMI Output: Type HDMI 1.3
  • Serial Digital Output:
    • Delay: < 5 µSec
    • Impedance: 75 O
    • Return Loss: >15 dB to 2.97 GHz
    • Max Cable Length:
      • 300 meters for 270 Mb/s
      • 100 meters for 1.485 Gb/s
      • 70 meters for 2.97 Gb/s
  • Analog Audio Output: 8 channels
