CAD 1700VP Boom Choir Mic Mail-In Rebate
Purchase Two 1700VPs from Full Compass and get $100 BACK from CAD Audio after mail-in rebate!... read more

CAD Audio 1700VP
Overhead Condenser Microphone with Variable Polar Pattern

OUR PART #:  1700VP

CAD Audio's 1700VP is a continuously-variable pattern condenser overhead microphone system with remote polar control and carbon fiber miniature boom.
Learn More
Our Price: $599.00
List Price: $779.00
You save 23%!
Write the first review.

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

CAD Audio 1700VP
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

CAD Audio's 1700VP is a continuously-variable pattern condenser overhead microphone system with remote polar control and carbon fiber miniature boom. The variable polar pattern with remote control allows the user to precisely adjust the shape of the pick-up pattern for best performance from a remote location. Utilizing a two-conductor shielded cable (max length 2,000 feet) between the microphone head and the pattern-control box, the user can adjust the polar pattern in real time without changing capsules, microphone positions, or inducing noise in the audio chain.

Special attention has been given to the frequency response and sensitivity of the microphone while utilizing the variable-pattern control to precisely alter the shape of the pick-up pattern. The large-diameter, low-noise elements produce a frequency response of 40Hz to 20KHz with a selectable, recessed 80Hz, 12dB/octave high-pass filter that removes unwanted low-frequency energy when engaged. The filter control is conveniently located on the control box. The microphone head is made of commercial grade aluminum, the control box is made of hardened steel, both are powder coated and made in the USA. The microphone head is painted matte black for an unobtrusive yet stylish appearance. The remote polar-pattern control box can be mounted in a single rack unit shelf with optional accessories.

Up to six control boxes can be mounted in one rack unit - Astatic RU1. The polar-pattern dial is positioned for easy adjustment ”on the fly” and can be secured with a single “Flat Style” blank panel when rack mounted.  The 1700VP has been designed to resist interference from devices such as cell phones, two-way communication devices and lighting apparatus. Utilizing our RF Resistant Architecture, the 1700VP meets the stringent RF standards set by the European Union (see the specification section for more information).

The 1700VP comes complete with 30' (9.1m) of two-conductor shielded cable terminated with a TA3F-type connector and 3-pin XLRM-type connector. Also included with the microphone system is a 3-pin XLRF-type connector on a stainless steel duplex wall plate, exclusive articulating steel hanger, and anti-twist thread and rods.  The 1700VP is primarily designed for recording and sound reinforcement of choirs, instruments and ambient miking.

The 1700VP can also be used for vocal pick-up in government, institutional and business applications.  The optional miniature-boom allows the microphone system to be used on a free-standing microphone post.

The 1700VP microphone system is designed to shorten the list of products an audio designer needs to consider when hanging microphones are specified. The remote variable polar pattern control allows the installer or end user the ability to change polar patterns when installed or from scene to scene. Adjustments to the pick-up pattern can be done ”on the fly“ without costly lifts, ladders and capsules. Choose the 1700VP for your next overhead microphone install.

CAD Audio 1700VP Features:

  • Continuously-variable polar pattern controllable from a remote location
  • Remote box is rack mountable up to six units per shelf
  • Blue LED status indicator on remote box
  • Selectable recessed high-pass filter for elimination of unwanted low-frequency energy
  • Securable controls with standard flat style blank rack panel, when rack mounted
  • RF (radio frequency) Resistant Architecture
  • Included 30’ (9.1m) cable, 56” adjustable length carbon fiber boom
Remote Variable Pattern Control Box
CAD Audio VPC-1-CAD Remote Variable Pattern Control Box
The CAD Audio VPC-1 is a remote variable pattern control box for microphones with variable pattern control. VPC-1 is rack mountable with the RU-1 up to 6 units per shelf. CAD Audio VPC-1 Specicifications: Dimensions: 6 x 1 x 4 inches
288.58 349.00 17

Usually ships in 7-14 business days.
Need it sooner? Call us!
Free Shipping Available

CAD 1700VP Boom Choir Mic Mail-In Rebate

Purchase Two 1700VPs from Full Compass and get $100 BACK from CAD Audio after mail-in rebate!

To qualify products must be on the same invoice:

Follow This Link To Begin Your Rebate Claim!

For More information on this offer or any CAD products please contact your Sales Pro at 800-356-5844.

CAD 1700VP Boom Choir Mic Mail-In Rebate
Offer good between 10/01/2017 and 02/28/2018 Click here for Cash Back coupon!

To be the first to review this item, click here.

Add to Cart

We're sorry, only of this item available



Call a Sales Pro at 800-356-5844 for more information
