Product Overview
Audio-Technica's BP4025 stereo condenser microphone is especially designed for broadcast and professional recording applications and offers large-diaphragm capsules in an innovative coincident capsule configuration. What this does is allows for a smaller housing while producing an X/Y stereo image with the realism an dspatial impact of a live sound field. It's ideal for use with professional audio and video gear, and is fully RoHS-compliant - that is, free from all substances specified in the EU directive on the reduction of hazardous substances (RoHS).
Applications
Professional Broadcast audio • Professional audio recording • Field audio capture
Includes
- BP4025 stereo condenser microphone
- AT8405a stand clamp for ⅜"-27 threaded stands
- Windscreen
- Soft protective pouch
Features
- Large-diaphragm capsules offer pristine sound quality and exceptionally low noise
- Innovative coincident capsule configuration produces accurate stereo image in smaller housing
- Compact, lightweight design is ideal for camera-mount use
- Excellent channel separation
- Phantom power operation - for use with professional equipment
- Switchable low-frequency roll-off and 10dB pad
- Includes one balanced cable (two 3-pin XLRM-type connectors at output)
- RoHS-compliant - free from all substances specified in the EU directive on the reduction of hazardous substances (RoHS)
Specifications
- Element: Fixed-charge back plate permanently-polarized condenser
- Polar Pattern: X/Y stereo
- Frequency Response: 20 - 17,000Hz
- Low Frequency Roll-off: 80Hz, 12dB/octave
- Open Circuit Sensitivity: -32dB (25.1mV) re 1V @ 1Pa
- Channel Balanced: < 2.5dB
- Impedance: 170Ω
- Maximum Input Sound Level:
- 145dB SPL, 1kHz @ 1% T.H.D.
- 155dB SPL, with 10dB pad (nominal)
- Dynamic Range (typical): 131dB, 1kHz @ Max SPL
- Signal-to-Noise Ratio: 80dB, 1kHz @ 1Pa
- Phantom Power Requirements: 11 - 52VDC, 7mA, typical (both channels total)
- Switch: Flat, roll-off; 10dB pad (nominal)
- Weight: 9.5oz.
- Dimensions:
- Length: 7.32"
- Head diameter: 1.87"
- Body diameter: 0.83"
- Output Connector: Integral 5-pin XLRM-type
- Cable: 16.5' long, 8-conductor, shielded, vinyl-jacketed stereo cable with 5-pin XLRF-type connector at microphone end and two 3-pin XLRM-type connectors at output end
- Note: further information can be found within the items located under the "Documentation" tab above.
