Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs and XLRs

OUR PART #: OX8-R MFR #: R800 8003

Copied to clipboard

The Radial Engineering OX8 is a high-performance 8-channel microphone splitter that lets you send a microphone signal to as many as three consoles at the same time. ...Read more

Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs And XLRs Image 1
Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs And XLRs Image 2
Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs And XLRs Image 3
Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs And XLRs Image 4
Radial Engineering OX8-r 8-Channel Mic Splitter, Eclipse Isolation Transformers, D-Subs And XLRs
Our Price: $1,099.99
List Price: $1,320.00
You save 17%!

SPECIAL FINANCING AVAILABLE

Synchrony Music & Sound Card
$31/mo* with 36 month financing. ‡
Limited Time. Learn How
Item usually available to ship in 5-9 Business Days. Please call for up-to-date information on product availability.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

The Radial Engineering OX8 is a high-performance 8-channel microphone splitter that lets you send a microphone signal to as many as three consoles at the same time. Each channel is configured with a balanced input, a direct out which also serves as a return path for 48V phantom power, a thru-put with ground lift switch and a transformer isolated output to eliminate hum and buzz, making this tool ultra quiet.

For maximum flexibility, several connector options are available. Inputs may be accessed via the front panel, using standard XLRs, or the rear panel, with a choice of either 25 pin D-subs (wired to the Tascam standard) or Euro screw-down terminal connectors (Note: Wire-end terminal blocks are sold separately). Outputs include D-subs and Euro connectors, which are also located on the rear panel. These make it easy to connect to popular multi-track recording systems while providing easy termination for permanent installations.

Although primarily designed for mic signals, the OX8 is equipped with a -36dB pad to accommodate line level sources, making the OX8 highly adaptable for all types of signal splitting. Several connector options are available to enhance flexibility. Inputs may be accessed via the front panel using standard XLRs, or via the rear panel with a choice of either 25 pin D-subs wired to the ProTools standard or screw-down Phoenix/Euro terminals which are commonly used in permanent installations.

Because the OX8 is 100% passive, it does not require any power whatsoever to make it work. You simply plug in and the transformers do all the work. The OX8 comes standard with Eclipse ET-MS10 mic bridging transformers or may be special ordered with premium transformers for the ultimate purist. Each channel is further advantaged with an ultra-short signal path and built in RF filters to ensure absolute quiet performance even in the most noise-prone environments.

The Radial Engineering OX8 is a professional recording tool that is equally at home in live touring, permanent installations or broadcast. For massive, high-performance routing possibilities, get the OX8 today!

Features

  • Balanced 8-channel mic splitter in single space 19" frame
  • 24 output channels (3 outputs per input)
  • Delivers exceptional audio without artifact
  • Eliminates hum and buzz caused by ground loops
  • -36 dB Pad allows for line level inputs
  • Ideally suited for live recording, PA and broadcast
  • Equipped with Radial Eclipse MS10 transformers

Specifications

  • Audio Circuit Type: Passive transformer-based mic level splitter
    • Transformer: Radial Eclipse MS10
    • Shield: Durable Faraday, MuMETAL can
  • Number of Channels: 8 channel 3-way splitter (1-in/3-out)
  • Frequency Response: 20 Hz - 18 kHz (+0 dB/-3 dB)
  • Dynamic Range: 140 dB
  • THD + Noise: 0.005% @ 1 kHz
  • Phase Deviation: 1° @ 100 Hz; 5° @ 20 Hz
  • CMRR: -114 dB @ 60 Hz
  • Inputs: XLR, Euroblock, DB-25
    • Input Impedance: 150 Ω, balanced
    • Input Pad: -36 dB (allows line-level sources)
    • Maximum Input: +2 dBu @ 20 Hz
  • Outputs: Euroblock, DB-26
    • Output Impedance: 150 Ω, balanced
  • Ground Lift: Disconnects XLR pin-1 at direct-2 and isolated output
  • XLR Configuration: AES Standard (pin-2 hot)
  • DB-25 Configuration: Tascam analog audio standard
  • Construction: 14-gauge steel
  • Finish: Durable powder coat
  • Dimensions (H x W x D): 1.75" x 19" x 6" (4.45cm x 48.25cm x 15.25cm)
  • Weight: 7.5 lbs (3.4 kg)
  • Conditions: For use in dry locations only, between 5° C and 40° C
  • Warranty: Radial 3-year, transferable
