Electro-Voice C8.2B-EVID
Pair of 8" Coaxial Ceiling Speakers, Black

OUR PART #:  C8.2B-EVID

Either 70V/100V or 8 ohm operation is standard on every model, and they are also acoustically matched to the EVID surface mount speaker line.
Learn More
Our Price: $387.00

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Electro-Voice C8.2B-EVID
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Either 70V/100V or 8 ohm operation is standard on every model, and they are also acoustically matched to the EVID surface mount speaker line. The EVID Ceiling Speaker line will solve any installation challenge, plus all installation accessories commonly needed for most jobs are included.

Never before has a ceiling speaker system delivered such a full range punch. Its specially tuned enclosure and 8" woofer provide amazing bass response. The 1" waveguide coupled tweeter give smooth controlled coverage out to 20 kHz. Perfect for installations where a flush mount design is desired but demand for high quality audio exists. Features a 4-point mounting system which makes installations fast and easy. Comes complete with mounting support ring and tile rails. No additional accessories needed for most installations. The model C8.2LP is identical to the C8.2 but in a low profile backcan for tight installation spaces.

NOTE: Product image shown is of WHITE version. Actual product is BLACK.

Electro-Voice C8.2B-EVID Includes:

  • Tile bridge
  • Mounting ring (for easy installation)

Electro-Voice C8.2B-EVID Features:

  • 8" coaxial two-way with extended LF
  • Waveguide coupled Ti Tweeter
  • Full bandwidth overload protection
  • Front baffle wattage tap adjustment
  • Integrated low loss matching transformer allows for either 70v/100v or 8-ohm operation
  • Integrated ported enclosure for extended bass response

Electro-Voice C8.2B-EVID Specifications:

  • Freq. Response (-10dB): 50Hz - 20kHz
  • Coverage (Conical): 110┬░
  • Power Handling: 100W Cont./400W Peak
  • Sensitivity (SPL 1w/1m): 91 dB
  • Max Calculated SPL: 117 dB
  • Impedance: 8 Ohms nominal (transformer bypass)
  • Network: Network and transducers protected, 12 dB/oct 2.6kHz
  • LF Transducer: 8in. (200mm) Polypropylene cone
  • HF Transducer: 1in. (25mm) Ti Mylar laminate
  • Transformer Taps:
    • 70V: 1.88, 3.75, 7.5, 15 or 30W
    • 100V: 3.75, 7.5, 15 or 30W
    • Bypass: 8 Ohms
  • Connectors: Phoenix type removable, with screw terminals and "loop-thru", accepts 12 gauge wire
  • Enclosure Material:
    • Baffle-UL 94V-O rated ABS
    • Backcan-Zinc plated steel
  • Grille: Perforated powder coated steel with safety tether
  • Support Hardware: Tile bridge, backing plate support, cutout template, paint shield
  • Dim. (H x Dia.): 10.0" x 10.6" (255mm x 270mm)
  • Cutout Size: 10.8" (274mm)
  • Net Weight (each): 11.0 lbs. (5.0 kg)
  • Shipping Weight (pair): 24.0 lbs. (11.0 kg)
