Switchcraft TTP96K3HN
Jack Panel, Half Normaled

OUR PART #:  TTP96K3HN

The TTP96K3HN features 3.5" high, half normals and offers the end user a rugged cable tray to support rear cabling.
Learn More
Our Price: $330.18
List Price: $528.28
You save 37%!
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Switchcraft TTP96K3HN
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

The TTP96K3HN features 3.5" high, half normals and offers the end user a rugged cable tray to support rear cabling. Heavy duty construction takes weight off the back of the jacks for increased reliability.

Features:

  • Kit features 96 TT jacks in one rack space (1.75" high) or two rack spaces (3.5" high)
  • Jack blocks can be removed from the front for easy soldering
  • Dust tray limits dirt, dust and contamination of jack terminals
  • Wire management straps are adjustable and reusable
  • Attractive, corrosion resistant nickel-plated jacks
  • Steel frame jack for superior jack life
  • Extra wide labeling strips provide maximum space
  • Rugged, attractive black anodized aluminum face will not break or rust
  • Three jack configurations available for the exact switching arrangement you need: full normal, half normal, and non-normal (open circuit)
  • Fanned solder terminals for easier solder connections
  • Gold switching contacts for long-term reliability in normal-through connections

Specifications:

Materials
Jacks:
Frame: Nickel-plated steel
Bushing: Nickel-plated brass
Tip, Ring and Shunt Springs: Nickel silver with welded contacts
Assembly Screws: Nickel-plated steel
Welded Contacts: Gold alloy

Panel:
Front Channel: Black anodized aluminum
Frame: C.R.S. black epoxy painted
Designation Strips: Black polycarbonate 94V-0
Designation Strip Covers: Clear polycarbonate
Jack Inserts: Thermoplastic polyester

Mechanical
Life: 30,000 cycles
Insertion Force: 7 lbs. maximum
Withdrawal Force: 1 lb. minimum
Operating: 0°C to +50°C

Electrical
Contact Resistance: 30 milliohms maximum initial
Insulation Resistance: 10,000 megohms maximum
Dielectric Withstanding Voltage: 500V at 60 Hz AC
Working Voltage: 140 VDC maximum
Current Rating: 100 milliamps
