Biamp R.5COAX66 12" 2-Way Full Range Coaxial Speaker, Weather Resistant

OUR PART #: R.5-COAX-66 MFR #: R.5-COAX-66

Copied to clipboard

The Community R.5COAX66 high fidelity is a two-way... ...Read more

Biamp R.5COAX66 12" 2-Way Full Range Coaxial Speaker, Weather Resistant Image 1
Biamp R.5COAX66 12" 2-Way Full Range Coaxial Speaker, Weather Resistant
Our Price: $1,486.00

SPECIAL FINANCING AVAILABLE

Synchrony Music & Sound Card
$42/mo* with 36 month financing. ‡
Limited Time. Learn How
Item usually available to ship in 9-12 Business Days. Please call for up-to-date information on product availability.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The Community R.5COAX66 high fidelity is a two-way, full-range loudspeaker system that's engineered to offer full-range quality sound in a range of indoor and outdoor applications. Its wide range, smooth frequency response, and high efficiency all ensure both high-fidelity music reproduction and excellent projection of clear, intelligible speech with very low distortion. Five-year limited product warranty; fifteen-year enclosure warranty.

Community R-Series - From the compact R.25 and R.5 on up to the powerful R6-51 model, there is a Community R-Series for every installation. Highly weather resistant for outdoor applications, but very appropriate for indoor use as well, the R-Series offers exceptional voice clarity and sound projection capability. R-Series systems are found in the world’s premier amusement parks, sports arenas, cruise ships, and race tracks as well as countless university and high school sports fields. All R-Series loudspeaker enclosures are warranted for structural integrity for 15 years.

Applications:

  • Convention centers
  • Fill speaker for stadia, athletic fields, arenas and race tracks
  • Outdoor background music / paging systems
  • Theme and amusement parks
  • Fairgrounds, rodeos, air shows
  • Malls, cruise ships, skating rinks
  • Swimming pools
  • Portable sound systems

Community R.5-COAX66 Features:

  • Weather-resistant, rotomolded UV enclosure
  • Weather-treated drivers and crossovers
  • Corrosion-resistant zinc-rich epoxy dual-layer powder coated steel grille and yoke
  • High fidelity
  • High efficiency
  • Integral mounting points
  • High power passive crossover
  • Optional 200W, 70V autoformer
  • Five-year product warranty / Fifteen-year enclosure warranty

Community R.5-COAX66 Specifications:

  • Loudspeaker Type: 2-way, coaxial, weather-resistant, full-range
  • Operating Range: 80 Hz to 18 kHz, 90 Hz to 12.5 kHz (±3.5 dB)
  • Max Input Ratings: 200W continuous, 500W program, 40 volts RMS, 89 volts momentary peak
  • Recommended Power Amplifier: 420W to 600W @ 8 ohms
  • Sensitivity (1W/1m): 98 dB SPL (100 Hz to 13 kHz 1/3 octave bands), 97 dBSPL (250 Hz to 4 kHz speech range)
  • Maximum Output: 121 dB SPL / 128 dB SPL (peak)
  • Nominal Impedance: 8 ohms
  • Minimum Impedance: 4.2 ohms @ 9.9 kHz, Nominal –6dB
  • Beamwidth:
    • H: 60° (+20° / -6°, 1.6 kHz to 12.5 kHz)
    • V: 60° (+20° / -3°, 1.6kHz to 12.5 kHz)
  • Axial Q / DI: 15.2 / 11.8, 1.6 kHz to 12.5 kHz
  • Crossover Frequency: 2 kHz
  • Recommended Signal Processing: 60 Hz high pass filter
  • Drivers:
    • LF: 1 x 12”
    • HF: 1 x 1” exit titanium free, Ferrofluid-cooled
  • Driver Protection: DYNA-TECH protection circuitry
  • Input Connection: 12 foot (4 m) SJOW #16 gauge
  • Controls: None
  • Enclosure: Rotomolded LLDPE, Light Grey
  • Mounting/Rigging Provisions: (5) 3/8-16 rigging points
  • Grille: 3-layer WeatherStop™, Light Grey (Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
  • Required Accessories: 24 dB/Oct high pass filter
  • Supplied Accessories: (1) Yoke bracket, light grey, (1) Aiming strap
  • Optional Accessories: PMB Series pole mount brackets
  • Dimensions (HxWxD): 16" x 16" x 15.94" (406.4 x 406.4 x 404.88 mm)
  • Weight:
    • Product: 35 lbs (15.9 kg)
    • Shipping: 42 lbs (19.1 kg)
  • Environmental Performance: IEC529 IP54W ratingwith a minimum 5-degree downward aiming angle
  • Community strives to improve its products on a continual basis. Specifications are therefore subject to change without notice.

Note:

1. Sensitivity: Free field pink noise measurement at 20 ft (6.1 m) at 50% power; extrapolated to 1 meter and an input of 2.83 volts RMS.

2. Watts: All wattage figures are calculated using the rated nominal impedance.
