Audio-Technica AT8010 Omnidirectional Condenser Mic, Battery or Phantom Powered

OUR PART #: AT8010 MFR #: AT8010

Copied to clipboard

The AT8010 from Audio-Technica is an an omnidirectional microphone that works great for interviews, capture of audience reaction, and musical events. ...Read more

Audio-Technica AT8010 Omnidirectional Condenser Mic, Battery Or Phantom Powered Image 1
Audio-Technica AT8010 Omnidirectional Condenser Mic, Battery Or Phantom Powered Image 2
Audio-Technica AT8010 Omnidirectional Condenser Mic, Battery Or Phantom Powered
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The AT8010 from Audio-Technica is an an omnidirectional microphone that works great for interviews, capture of audience reaction, and musical events. Its omni polar pattern provides maximum ambient pickup. It has an extremely smooth, extended response, both on- and off-axis, and can operate on either battery or phantom power.

Applications

Ideal for:

Interviews • Group vocals • Strings • Cymbal overheads • Acoustic guitar and piano

Includes

  • AT8010 microphone
  • AT8405a stand clamp for ⅝"-27 threaded stands
  • ⅝"-27 to ⅜"-16 threaded adapter
  • Windscreen
  • Battery
  • Soft protective pouch

Features

  • Omnidirectional polar pattern provides maximum ambient pickup
  • Extremely smooth, extended response on- and off-axis
  • Low sensitivity to popping and overload
  • Operates on battery or phantom power
  • RoHS compliant—free from all substances specified in the EU directive on hazardous substances

Specifications

  • Element: Fixed-charge back plate permanently-polarized condenser
  • Polar Pattern: Omnidirectional
  • Frequency Response: 20 - 20,000Hz
  • Low Frequency Roll-Off: 80Hz, 12dB/octave
  • Open Circuit Sensitivity: Phantom: -44dB (6.3mV) re 1V @ 1Pa; Battery: -45dB (5.6mV) re 1V @ 1Pa
  • Impedance: Phantom: 250Ω; Battery: 300Ω
  • Maximum Input Sound Level: Phantom: 137dB SPL, 1kHz @ 1% T.H.D.; Battery: 123dB SPL, 1kHz @ 1% T.H.D.
  • Dynamic Range (typical): 113dB, 1kHz @ Max SPL; Battery: 99dB, 1kHz @ Max SPL
  • Signal-to-Noise Ratio: 70dB, 1kHz @ 1Pa
  • Phantom Power Requirements: 11-52VDC, 2mA typical
  • Battery Type: 1.5V AA / UM3
  • Battery Current/Life: 0.4mA / 1200 hours typical (alkaline)
  • Switch: Flat, roll-off
  • Weight: 5.8oz. (165g)
  • Dimensions:
    • Length: 7.01" (178.0mm)
    • Head diameter: 1.02" (26.0mm)
  • Output Connector: Integral 3-pin XLRM-type
  • Note: further information can be found within the items located under the "Documentation" tab above.
