Paging Horn Surface Mount Speaker Assembly


Our Price: $110.60
List Price: $161.22
You save 31%! (Low Price Guarantee)
In Stock

The QUAM SYSTEM 6VP is a complete loudspeaker assembly with double re-entrant horn, compression type loudspeaker, 16W- 25/70.7V pigtail transformer, 16 gage square steel baffle and enclosure Mounting hardware is #8-32 ’pin-in-torx’.

Quam System 6VP System Components:

  • Baffle and Enclosure Finish: White baked epoxy hybrid
  • Loudspeaker H16
  • Transformer Integral to unit 25/70V 16W- 5 tap Color-coded leads (16W, 8W, 4W, 4W, 1W)
  • Baffl e BS8WS
  • Enclosure SE1WV

Quam System 6VP Specifications:

  • Average Sensitivity 110 dB-SPL 1W/1M
  • Loudspeaker Power Rating 16W RMS EIA 426A Standard
  • Calculated Maximum
  • System Output
  • 121 dB-SPL 5W/1M
  • Frequency Response 350 Hz - 10 kHz EIA 426A Standard
  • Nominal Coverage Angle 90° included angle -6 dB/ 2kHz, half space
  • Audio Connection Pre-cut 7” color coded leads

Click to download

Add to Cart

We're sorry, only of this item available

Call a Sales Pro at 800-356-5844 for more information
