Sennheiser e 614 Supercardioid Condenser Instrument Microphone

OUR PART #: E614 MFR #: 009895

Copied to clipboard

The e 614 is a super-cardioid condenser microphone, designed for demanding instrument recordings and performances that require extended frequency response, high SPL handling... ...Read more

Sennheiser e 614 Supercardioid Condenser Instrument Microphone Image 1
Sennheiser e 614 Supercardioid Condenser Instrument Microphone Image 2
Sennheiser e 614 Supercardioid Condenser Instrument Microphone Image 3
jXXZh-bCe2o
1 Video
Sennheiser e 614 Supercardioid Condenser Instrument Microphone
Our Price: $199.95
List Price: $249.00
You save 20%!
Synchrony Music & Sound Card
No Interest if paid in full within 6 Months
Learn How
More On Order! Due to high demand, this item has a backorder of over 21 days. Call our Sales Pros at 800-356-5844 for more information.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

The e 614 is a super-cardioid condenser microphone, designed for demanding instrument recordings and performances that require extended frequency response, high SPL handling, fast transient response and compact size. While drumset overhead miking was the first design priority, the e614 also works exceptionally well on percussion setups as well, fitting comfortably into tight setups. The e 614 can handle high SPLs and features medium sensitivity, which ensures reduced bleed from other instruments on stage. Because of its excellent acoustic properties, this mic is also ideal for home recording.

Applications

  • Drums and percussion
  • Overhead miking

Includes

  • e 614 Instrument Microphone
  • Microphone clip
  • Microphone pouch

Features

  • Excellent directivity over the entire frequency range (40Hz - 20kHz)
  • Natural sound for flexible applications
  • Designed for high SPLs
  • Rugged build that's ready for road and studio use
  • Includes mic clip and pouch

Specifications

  • Dimensions: Dia. 20mm, L = 100mm
  • Connector: 3-pin XLR
  • Frequency response: 40Hz - 20kHz
  • Transducer principle: Pre-polarized condenser microphone
  • Weight without cable: 93g
  • Pick-up Pattern: Supercardioid
  • Sensitivity in free field, no load (1kHz): 3mV/Pa = - 50dB (0dB = 1 V/Pa)
  • Nominal impedance: 50Ω
  • Minimum terminating impedance: 1000Ω
  • Phantom powering: 12 – 52V / 3mA
  • Equivalent noise level: 24dB (A)
  • Equivalent noise level weighted as per CCIR468-3: 35dB
  • Maximum sound pressure level (passive): 139dB/SPL
