Bogen Communications M450
Power Amp, Stereo 450W/Ch @ 4-Ohms, 300W/Ch @ 8-Ohms, 900W @ 70V mono

OUR PART #:  M450

Bogen's M-Class series is designed for reliability, flexibility, and power...
Learn More
Our Price: $1,127.10
List Price: $1,371.91
You save 18%!

Full Compass offers free ground shipping on thousands of stock and non-stock (special order) items for orders placed on this web site and shipping in the continental US (48 states).

Learn More

Free Shipping

Available

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Bogen Communications M450
Qty:
Usually ships in 7-14 business days.
Need it sooner? Call us!

Similar Products

Bogen's M-Class series is designed for reliability, flexibility, and power, and features three modes of operation: Stereo, 70V Mono, or Dual Mono; and 2 modular input bays for a variety of prioritized input types. Additional features include Bogen's patented Back-Slope circuitry for regulating the proper amount of AC energy from the amplifier's power toroid, an energy-saving Sleep Mode, and support for up to two input modules with up to two priority settings with the ability to add other modules as needed.

Bogen M450 Features:

  • 3 modes of operation to choose from - Stereo, Dual Mono, or 70V Mono
  • Low noise, low distortion, and high slew rate
  • Flexible modular input capability (2 module capacity)
  • Professional, dual-channel (balanced or unbalanced), high-impedance input module with gain selection included
  • 3 selectable low-frequency, roll-off choices
  • 2x1 mixer function when in mono modes
  • Insert connections for outboard equipment (in mono modes)
  • Post- and Pre-EQ Output Feeds (summed mono out in stereo mode)
  • DC, overload, short circuit, and thermal protection circuits Clip limiting circuits for speaker protection
  • Power-saving Sleep Mode for intermittent use applications
  • Status, Signal, and Clip/Limit indicators
  • Back-Slope AC voltage stabilization for dependable performance over varying AC line voltages
  • Heavy-gauge steel chassis with cast aluminum front panel
  • Recessed volume control knobs with snap-on protective cover
  • Mounts in 2 rack spaces (3-1/2") directly stackable without need for extra space above or below
  • 2 independent, continuously variable, cooling fans for dependable and quiet operation
  • Easily removable front fan grilles with filters
  • Stable into 2-ohm loads

Bogen M450 Specifications:

  • Power Output:
    • 70V Mono: 900W @ 5.5 ohms
    • 4-ohm: 450W perchannel
    • 8-ohm: 300W per channel
  • Input Sensitivity: 1.010V for 450W @ 4 ohms
  • S/N Ratio (20K BW): 106 dB ref. 8 ohms, F.P.
  • Class of Operation: H
  • Product Weight: 44 lbs
  • Connectors:
    • Power: 15A line cord
    • Input: 2 new Bogen std. 12-pin connector modules/RCA input
    • Output: 5-pin "touch-proof" Barrier Strip, RCAPre- & Post-EQ Output
  • Power Bandwidth: 20-40kHz .5% THD
  • THD @ 1 kHz rated power: less than .02%
  • Load Impedance: 4-8 ohms, 70V
  • Minimum Load Impedance (Stereo): 3.2 ohms
  • Frequency Response @ 1 watt: 20-20kHz +/-0.25dB
  • Output Regulation:
    • 1kHz Direct: 0.5dB @ 8 ohms
    • 1kHz Bridged: 1.5dB @70V
  • Inputs (Plug-in modules): Electronically balanced, high-impedance module standard, other modular input types available
  • AC Input Voltage Range: 95-130V AC, 60Hz
  • Maximum AC Current: 15A
  • Indicators: Status (On/Protect/Sleep), Clip/Limit, Signal
  • Temperature Range: 15 to 105 degrees F
  • Cooling: Forced Air Variable Speed Fan
  • Dimensions (W x H x D): 17" x 3 1/2" x 16"
  • Protection: RF, DC, Low-frequency, Thermal, Low-Impedance,Circuit-Breaker, Short Circuit
  • Special Features: Sleep Mode, Back-Slode regulation, Stereo, Dual Mono, 70V Mono Operation, Toroidal Power Transformer
