Audio-Technica AE5100 Large-Diaphragm Cardioid Condenser Instrument Microphone

OUR PART #: AE5100 MFR #: AE5100

Copied to clipboard

Delivering uncompromising sound quality, the Artist Elite® AE5100 large-diaphragm cardioid condenser instrument microphone from Audio-Technica works great for overheads... ...Read more

Audio-Technica AE5100 Large-Diaphragm Cardioid Condenser Instrument Microphone Image 1
Audio-Technica AE5100 Large-Diaphragm Cardioid Condenser Instrument Microphone Image 2
Audio-Technica AE5100 Large-Diaphragm Cardioid Condenser Instrument Microphone Image 3
IhuURBsFrHs?rel=0
3 Videos
Audio-Technica AE5100 Large-Diaphragm Cardioid Condenser Instrument Microphone
Our Price: $299.00
Synchrony Music & Sound Card
No Interest if paid in full within 6 Months
Learn How
Item usually available to ship in 14-17 Business Days. Please call for up-to-date information on product availability.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Accessories

Product Overview

Delivering uncompromising sound quality, the Artist Elite® AE5100 large-diaphragm cardioid condenser instrument microphone from Audio-Technica works great for overheads, percussion, acoustic guitar, strings and other acoustic instruments as well. It provides rich, warm and accurate sound, while also incorporating the most essential ingredients needed for quality live sound in a choir microphone. The mic's large-diaphragm capsule brings forth accurate, natural response, and its low-profile design enables innovative and creative placement options. Engineered with a lower profile than the other large studio microphones to which it compares sonically, it offers an exceptional performance-to-size ratio. And with its low noise and smooth response, the AE5100 is ideal for studio recording as well.

Includes

  • AE5100 microphone
  • AT8471 isolation clamp for ⅝"-27 threaded stands
  • ⅝"-27 to ⅜"-16 threaded adapter
  • AT8136 windscreen
  • Soft protective pouch

Features

  • Large-diaphragm capsule delivers accurate and natural response
  • Low-profile design permits innovative placement options previously unattainable with a large-diaphragm condenser
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Robust design for enduring dependability on the road
  • Includes isolation clamp for shock protection, secure mounting and easy positioning
  • Integral 80Hz HPF switch and 10dB pad

Specifications

  • Element: Fixed-charge back plate, permanently-polarized condenser
  • Polar Pattern: Cardioid
  • Frequency Response: 20Hz - 20kHz
  • Low Frequency Roll-off: 80Hz, 12dB/octave
  • Open Circuit Sensitivity: -36dB (15.8mV) re 1V @ 1Pa
  • Impedance: 150Ω
  • Maximum Input Sound Level: 148dB SPL, 1kHz @ 1% T.H.D.; 158dB SPL with 10dB pad (nominal)
  • Noise: 11dB SPL
  • Dynamic Range (Typical): 137dB, 1kHz @ Max SPL
  • Signal-to-Noise Ratio: 83dB, 1kHz @ 1Pa
  • Phantom Power Requirements: 11-52VDC, 3.2mA typical
  • Switches: High-pass filter; 10dB pad (nominal)
  • Weight: 5.0oz. (143g)
  • Dimensions (L x diameter max): 5.85" x 1.02" (148.5 x 26mm)
  • Output Connector: Integral 3-pin XLRM-type
  • Note: further information can be found within the items located under the "Documentation" tab above.
