West Penn C207-BY-FOOT
Cable, 12Ga 2C Cluster Speaker, By the Foot

OUR PART #  C207-BY-FOOT

Cable, 12Ga 2C Cluster Speaker, By the Foot
Our Price: $1.05
List Price: $1.37
Save up to 51% when you order by quantity!
Buy 50 @ $0.84 ea.
Buy 200 @ $0.75 ea.
Buy 400 @ $0.67 ea.
(Low Price Guarantee)

This product must be purchased in multiples of 10

Qty:
In Stock

12/2 Stranded bare copper conductors, unshielded and unjacketed - Cluster Speaker Cable.

CONSTRUCTION PARAMETERS

  • Conductor: 12AWG Bare Copper
  • Stranding: 65x30
  • Insulation Material: PVC/Nylon
  • Insulation Thickness: 0.015" PVC Nom. // 0.005" Nylon Nom.
  • Number of Conductors: 2
  • Shield: None
  • Drain: None
  • Jacket Material: None
  • Jacket Thickness: None
  • Overall Cable Diameter: 0.260" Nom.
  • Approximate Cable Weight: 52lbs/1M' Nom.
  • Flame Rating: UL1685

ELECTRICAL & ENVIRONMENTAL PROPERTIES

  • Temperature Rating: -4 degrees F to 140 degrees F
  • Operating Voltage: 300VRMS
  • Max. Capacitance Between Conductors @ 1kHz: 36pf/ft Nom.
  • DC Resistance per Conductor @ 68 degrees F
  • Insulation Colors: Black, Red
  • Jacket Color: None
  • RoHS Compliant: NO

MECHANICAL PROPERTIES

  • Max. Recommended Pull Tension: 146 lbs
  • Min. Bend Radius (Install): 2.6"



West Penn C207-BY-FOOT
Cable, 12Ga 2C Cluster Speaker, By the Foot

OUR PART #  C207-BY-FOOT

Product Information:

12/2 Stranded bare copper conductors, unshielded and unjacketed - Cluster Speaker Cable.

CONSTRUCTION PARAMETERS

  • Conductor: 12AWG Bare Copper
  • Stranding: 65x30
  • Insulation Material: PVC/Nylon
  • Insulation Thickness: 0.015" PVC Nom. // 0.005" Nylon Nom.
  • Number of Conductors: 2
  • Shield: None
  • Drain: None
  • Jacket Material: None
  • Jacket Thickness: None
  • Overall Cable Diameter: 0.260" Nom.
  • Approximate Cable Weight: 52lbs/1M' Nom.
  • Flame Rating: UL1685

ELECTRICAL & ENVIRONMENTAL PROPERTIES

  • Temperature Rating: -4 degrees F to 140 degrees F
  • Operating Voltage: 300VRMS
  • Max. Capacitance Between Conductors @ 1kHz: 36pf/ft Nom.
  • DC Resistance per Conductor @ 68 degrees F
  • Insulation Colors: Black, Red
  • Jacket Color: None
  • RoHS Compliant: NO

MECHANICAL PROPERTIES

  • Max. Recommended Pull Tension: 146 lbs
  • Min. Bend Radius (Install): 2.6"
