Neutrik NL4FC-B 4-Pole Speakon Cable Connector, Black Housing

OUR PART #: NL4FC-B MFR #: NL4FC-B

Copied to clipboard

The Neutrik NL4FC-B is a 4 pole cable connector with chuck type strain relief, black houing, gold latch and gold contacts. ...Read more

Neutrik NL4FC-B 4-Pole Speakon Cable Connector, Black Housing Image 1
Neutrik NL4FC-B 4-Pole Speakon Cable Connector, Black Housing
No longer available at Full Compass
We've left this page up for reference only.

Questions? Contact our
Sales and Service Pros for expert
advice and package pricing.

800-356-5844

Email customer service

Product Overview

The Neutrik NL4FC-B is a 4 pole cable connector with chuck type strain relief, black houing, gold latch and gold contacts. The NL4FC-B is the industry-standard for loudspeaker connections and offers extremely reliable and robust cable connectors with a reliable locking system. They feature solid contacts with screw-type terminals including a stranded wire protection which also offer solder termination.

Features

  • Up to 30 A rms current rating
  • Reliable and robust, easy and fast to assemble
  • Cable strain relief for 6 - 15 mm cable O.D.
  • Accurate and dependable twist lock latching system "Quick Lock"
  • Glass reinforced material for insert and housing, long-lasting and dependable
  • User friendly latch design for easy handling
  • Unique Neutrik chuck type strain relief
  • Branded with unique hologram - guarantees genuine and authentic Neutrik product

Specifications

  • Electrical:
    • Contact Resistance: < / = 3 Megohms (inner) (after lifetime)
    • Dielectric Strength: 4 kVdc (peak)
    • Insulation Resistance: > 1 Gigohms (after damp heat)
    • Rated Current per Contact: 30 A rms continuous
    • Rated Current per Contact: 40 A audio signal, duty cycle 50 %
    • Rated Voltage: 250 V (Insulation)
    • Attention: speakON is NOT to be used as an AC mains or power supply connector!
  • Mechanical:
    • Cable O.D.: 6 - 15 mm
    • Cable Retention: >/= 220 N (subject to cable O.D. and material)
    • Lifetime: > 5000 mating cycles
    • Wiresize: 4 sq. mm
    • Wiresize: 12 AWG
    • Wiring: screw type terminals or soldering
    • Locking Device: Quick Lock (latch)
  • Material:
    • Contact Plating: 4 µm Ag
    • Contacts: Brass (CuZn39Pb3)
    • Insert: PBTP 20 % GR
    • Locking element: Zinc diecast (ZnAl4Cu1)
    • Shell: Polyamide (PA 6 30 % GR)
    • Strain Relief: Polyacetal (POM)
  • Environmental:
    • Flammability: UL 94 V-0
    • Solderability: Complies with IEC 68-2-20
    • Temperature Range: -30 °C to +80 °C
