Bogen Communications HTA125A
Power Amplifier, 125 Watt, 4-ohm/8-ohm/70V

OUR PART #:  HTA125A

The Bogen HTA Professional Series Power Amplifiers are high-performance units employing stateof- the-art Power MOSFET technology.
Learn More
Our Price: $607.57
List Price: $714.03
You save 15%!
Write the first review.

We guarantee to match pricing on the products we sell for new, identical and immediately available products if you see them offered at a lower price. Please contact us if you find a lower price before purchasing.

Learn More

Low Price

Guaranteed

Bogen Communications HTA125A
Qty:
Please call for availability.

Similar Products

The Bogen HTA Professional Series Power Amplifiers are high-performance units employing stateof- the-art Power MOSFET technology. The characteristics of Power MOSFETS make them ideally suited to power amplifier design, providing far superior performance and reliability compared to other types of transistors. They afford higher efficiency,reduced heat,simpler overall design, reduced size and weight.

The Model HTA125A supplies 125 watts (rms continuous output) at less than 0.5% total harmonic distortion from 20 to 20,000Hz.An input signal of only 500mV is required for full rated output. The input impedances are: high-impedance (50,000 ohms) unbalanced; low-impedance (500/600 ohms, balanced or unbalanced) with optional accessory transformer Model TL600. Line-bridging can be achieved with an optional transformer Model TL100. Residual hum and noise is at least 90dB below rated output and the output regulation is better than 2dB from no load to full load.

The HTA125A can drive a variety of load impedances: outputs include 4 ohms, 8 ohms, 25 VCT and 70.7 volts. It is capable of safely driving any recommended load continuously. The HTA125A is thermally protected to prevent damage due to excessively high temperatures;however,the amplifier will deliver the full rated power output continuously, even at +55ºC (+131ºF).Additional failure-preventive devices include electronic overload limiting, short circuit protection, and a slo-blo fuse.

Electronic shutdown circuitry is automatically activated if an overload or short circuit occurs and a front panel overload shutdown LED illuminates. Once the cause has been rectified, the unit automatically resets. The power on/off switch, located on the front panel, illuminates when the power is on.The rear panel contains an input level control, input and output connections, the ac line fuse,and an auxiliary receptacle.A lowcut filter switch is located internally.

Bogen Communications HTA125A Features:

  • 125 Watts
  • Designed for continuous operation at rated power, up to 120°F; convection-cooled
  • Thermal protection and automatic electronic overload protection
  • Hi-Z unbalanced and Lo-Z balanced or unbalanced input w/ accessorytransformer (TL600)
  • 4-ohm, 8-ohm, 25V, & 70V outputs

Bogen Communications HTA125A Specifications:

  • Frequency Response: ±1dB,20 to 20,000Hz at full rated output
  • Input Sensitivity: Hi-Z,500mV;Lo-Z balanced,with optional transformer,100mV
  • Hum and Noise: 90dB below rated output
  • Output Loads: 4 ohms,8 ohms,25VCT (5 ohms),70.7V (40 ohms)
  • Output Regulation: Better than 2dB from no load to full load
  • Input Impedances:
    • Hi-Z,50,000 ohmsunbalanced; Lo-Z,600 ohms, balanced or unbalanced
    • 1:1bridging with optional plug-in transformers
  • Low-Cut Filter: -10dB @ 100Hz
  • Controls & Indicators:
    • Front Panel —Illuminated on/off power switch and overload shutdown LED
    • Rear Panel — Input level control, Slo-Blo fuse
    • Internal — Low-Cut filter switch
  • Power Requirements: 120VAC, 60Hz, 260 watts @ Full Rated Output (Idle 45W)
  • Overload Protection:
    • Electronic overload protection
    • Electrical — 4A Slo-BloFuse
    • Thermal — 105ºC - 220ºF Thermostat
  • Operating Temperature Range: -20ºC (-4ºF) to +55ºC (+131ºF) at rated output
  • Auxiliary Receptacle (not switched): Three-wire grounded*,300 watts maximum
  • Dimensions (W x H x D, w/o feet): 19” x 11” x 5-1/4” (48.3 x 27.9 x 13.3cm)
  • Front Panel Dimensions (W x H): 19” x 5-1/4” (48.3 x 13.3 cm)
  • Finish: Black
  • Weight: 36 lbs. (16.3 kg)
  • Rated Output Power: 125 watts rms
  • Total Harmonic Distortion: Less than 0.5%, 20 to 20,000Hz at full rated output
  • Accessories:
    • 600-ohm line-matching transformer (Model TL600)
    • 1:1 line-matching transformer (ModelTL100)
