Belden 9729-1000
Wire, AES/EBU, 24awg, 2 pr, 1000ft

OUR PART #:  9729-1000

24 AWG stranded (7x32) tinned copper conductors, Datalene® insulation, twisted pairs...
Learn More
Our Price: $1,243.50
Write the first review.
Belden 9729-1000
Qty:
In Stock

Related Products

24 AWG stranded (7x32) tinned copper conductors, Datalene® insulation, twisted pairs, individually Beldfoil® shielded (100% coverage), 24 AWG stranded tinned copper drain wire, PVC jacket.

Specifcations:

Conductor
AWG: 24
# Conductor: 2
Stranding: 7x32
Conductor Material: TC - Tinned Copper .024 in.

Insulation
Insulation Material:
Insulation Trade Name: Datalene®
Insulation material: FPE - Foam Polyethylene
DIA: .061 in.

Inner Shield
Inner Shield Material:
Inner Shield Trade Name: Beldfoil® (Z-Fold®)
Type: Tape
Inner Shield Material: Aluminum Foil-Polyester Tape
Coverage (,%): 100

Inner Shield Drain Wire AWG:24
Inner Shield Drain Wire Stranding: 7x32
Inner Shield Drain Wire Conductor Material: TC - Tinned Copper

Outer Jacket
Outer Jacket Material:
Outer Jacket Material: PVC - Polyvinyl Chloride
Overall Cabling
Overall Nominal Diameter: 0.266 in.

Pair
Pair Color Code Chart:
1 Black & Red
2 Black & White

Pair Lay Length & Direction:
Lay Length (in.): 1.100
Twists/ft. (twist/ft): 10.900

Click to download
