Williams AV ANT 005 Remote Coaxial Antenna for FM Transmitters, 72-76 MHz

The ANT 005 from Williams AV is a Remote Coaxial Antenna, that measures 22ft overall in length with the last 80" being active antenna. Made for operating frequency of 72 MHz to 76 MHz FM; for use with large-area FM transmitters. Also works with optional 50ft antenna extension (WCA 008 50, sold separately).

ANT 005 Specifications

• Used with: T45, T27, T35 Transmitters (all sold separately)
• Connector type: F-connector
• Cable type: RG 59 coax
• Nominal Impedance: 75 Ω
• Total Cable Length: 22ft
• Active Antenna Length: 80"
• Shipping:
  • Dimensions: 9" x 5" x 7"
  • Weight: 1.0 lbs.
• ROHS approved
